About graphw00f

graphw00f is a GraphQL fingerprinting tool for GQL nodes, which can send both benign and malicious query requests to help researchers identify and determine the GraphQL engine behind the target application.

graphw00f can provide immediate security defense strategies for each technology and whether the related security protection technologies are enabled or disabled by default to a wide range of researchers. Carefully constructed query requests cause different GraphQL servers to respond differently to queries, mutations, and subscriptions, enabling us to fingerprint the backend engine and distinguish different GraphQL implementations.

Security Detection

graphw00f： A powerful GraphQL server engine fingerprinting tool

The current version of graphw00f will attempt to detect and identify the following GraphQL engines:

Graphene - Python
Ariadne - Python
Apollo - TypeScript
graphql-go - Go
gqlgen - Go
WPGraphQL - PHP
GraphQL API for WordPress - PHP
Ruby - GraphQL
graphql-php - PHP
Hasura - Haskell
HyperGraphQL - Java
graphql-java - Java
Juniper - Rust
Sangria - Scala
Flutter - Dart
Diana.jl - Julia
Strawberry - Python
Tartiflette - Python

GraphQL Technology Defense Matrix

Each fingerprint technology (such as Graphene, Ariadne, etc.) has a related document (such as Graphene), which covers the specific security defense mechanisms supported by the technology, so as to better understand how to implement attacks.

| Field Suggestions | Query Depth Limit | Query Cost Analysis | Automatic Persisted Queries | Introspection | Debug Mode | Batch Requests

|-------------------|-------------------|---------------------|-----------------------------|--------------------|------------|-----------------|

| On by Default | No Support | No Support | No Support | Enabled by Default | N/A | Off by Default

Tool Dependencies

python3
requests

Tool Installation & Running

Firstly, we need to use the following command to clone the project source code locally:

git clone git@github.com:dolevf/graphw00f.git

Next, run graphw00f using the following command and view the tool's help information:

python3 main.py -h

Usage: main.py -t http://example.com/graphql -f
Options:
-h, --help             show this help message and exit
-r, --noredirect        Do not follow redirections given by 3xx responses
-t URL, --target=URL   target url with the path
-f, --fingerprint        fingerprint mode
-d, --detect            detect mode
-T TIMEOUT, --timeout=TIMEOUT
Request timeout in seconds
-o OUTPUT_FILE, --output-file=OUTPUT_FILE
Output results to a file (CSV)
-l, --list             List all GraphQL technologies that graphw00f can
detect
-v, --version           Print out the current version and exit.

Tool usage

Identify GraphQL fingerprint

In this example, we will identify the specific location of a GraphQL node:

python3 main.py -f -t https://demo.hypergraphql.org:8484/graphql
+-------------------+
|   graphw00f
+-------------------+
***           ***
**                  ***
**                       **

+--------------+            +--------------+
|   Node X   |            |   Node Y   |
+--------------+            +--------------+

***           ***
**        **
**   **
+------------+
|   Node Z   |
+------------+
graphw00f - v1.0.4
The fingerprinting tool for GraphQL
Dolev Farhi <dolev@lethalbit.com>
[*] Checking if GraphQL is available at https://demo.hypergraphql.org:8484/graphql...

[*] Found GraphQL...

[*] Attempting to fingerprint...

[*] Discovered GraphQL Engine: (HyperGraphQL)

[!] Attack Surface Matrix: https://github.com/dolevf/graphw00f/blob/main/docs/hypergraphql.md

[!] Technologies: Java

[!] Homepage: https://www.hypergraphql.org

[*] Completed.

Detect and identify GraphQL fingerprints

In this example, graphw00f can detect the active status of GraphQL and execute the fingerprinting process:

python3 main.py -f -d -t http://localhost:5000

+-------------------+

|   graphw00f
+-------------------+

***           ***
**                  ***
**                       **
+--------------+            +--------------+

|   Node X   |            |   Node Y   |
+--------------+            +--------------+

***           ***

**        **
**   **
+------------+
|   Node Z   |
+------------+

graphw00f - v1.0.4

The fingerprinting tool for GraphQL
Dolev Farhi <dolev@lethalbit.com>
[*] Checking http://dvga.example.local:5000/graphql
[!] Found GraphQL at http://dvga.example.local:5000/graphql
[*] Attempting to fingerprint...
[*] Discovered GraphQL Engine: (Graphene)
[!] Attack Surface Matrix: https://github.com/dolevf/graphw00f/blob/main/docs/graphene.md
[!] Technologies: Python
[!] Homepage: https://graphene-python.org

[*] Completed.
