In-depth analysis of the security risks and shutdown posture in SEAndroid

I. Background

SEAndroidis a set of security mechanisms applied by Google on the Android system based onSELinuxas the core system security mechanism (hereinafter referred to as SELinux). It was first released in Android 4.3, and after many years of development, it has become an important guarantee for user-space security in Android.

In recent security research, the No恒 Laboratory has focused onSELinuxSome research results on the attack surface and attack methods of SELinux are shared here, hoping to engage in learning and exchange with the industry.

SELinux (Security-Enhanced Linux)is a Linux kernel security module led by the National Security Agency (NSA), which providesMandatory Access Control (MAC)It was released to the open source community in 2000 and integrated into the upstream Linux kernel in 2003. 'So, an excellent security mechanism is to disclose all details while still keeping attackers at bay :)'

The default access control strategy of Linux isDiscretionary Access Control (DAC)The following two figures can be used to intuitively understand the difference between DAC and MAC:

The image source is https://blog.csdn.net/headwind_/article/details/119704755

InDACin, the owner of the object can arbitrarily modify or grant the corresponding permissions to this object, and theoretically, the permissions owned by the process are the same as those of the user executing it; this leads to ifrootthe process with permission is attacked, the attacker can take advantage of this to freely operate in the system.

inMACIn it, security contexts are set for all processes and files. When a user performs an operation, in addition to passingDACinspection, it still needs to comply withMACrules; Therefore, even ifrootprocess, and their permissions will also be restricted to a specific range. Although this cannot completely prevent attacks, it can reduce the loss to the lowest possible level.

2. Implementation of SELinux

The implementation of SELinux depends on theSecurity Module Framework (LSM)When the kernel handles user-space access, LPM reserves a hook function after DAC checking, and SELinux implements MAC through this interface; therefore, the permissions on the Android platform areDAC+MACThat is, two permission management mechanisms exist independently, and operation behaviors must pass the inspection of both mechanisms to be allowed.

https://www.kernel.org/doc/ols/2002/ols2002-pages-604-617.pdf

3. Basic Elements

3.1 Tag

SElinuxis a tagging-based system, and all processes, files, sockets, etc. have tags. A tag is a four-tuple stringuser:role:type:levelAmong them, we mainly focus ontype.

In the Android system, all objects can be roughly divided into two categories:

• One isDeadof (files, ports, system properties, etc. that are called), for example:u:object_r:proc:s0

• One isLiveof (processes, Apps, etc. that call resources), for example:u:r:vendor_init:s0

The method to view labels is to add -Z to the commonly used commands, as follows:

process ps -ZAu:r:vendor_init:s0 root 545 1 6728 2376 poll_sche+ 0 S init u:r:zygote:s0 root 678 1 4308756 142888 poll_sche+ 0 S zygote64 file ls -lZdrwxr-x--- 2 root shell u:object_r:rootfs:s0 4096 2009-01-01 00:00 sbin drwxr-xr-x 18 root root u:object_r:vendor_file:s0 4096 2009-01-01 00:00 vendor attribute getprop -Z [DEVICE_PROVISIONED]: [u:object_r:default_prop:s0] [aaudio.hw_burst_min_usec]: [u:object_r:exported_default_prop:s0]

3.2 Rule

WithlabelsAfter that, you need to writerulesto limit labels. According to SELinux specifications, the complete statement format for rules is as follows:

rule_name source_type target_type:class perm_set

• rule_name rule name

  • allow: Allows the subject to perform operations on the object

  • neverallow: Refuses the subject to perform operations on the object

  • dontaudit: Indicates that information about a violation of the rule is not recorded

  • auditallow: Records information about a decision, usually SELinux only records failed information. Applying this rule will record successful decision information

• source_type subject

  • Domain: A label of a process or a set of processes. Also known as domain type

• target_type entity

  • Type: A label of an object (such as, file, socket) or a set of objects

• class category

  • The type of object to be accessed, such as files, sockets, etc.

  • Insystem/sepolicy/private/security_classesis defined in

• perm_set action set

  • operations to be performed, such as read, write, etc.

  • Insystem/sepolicy/private/access_vectorsis defined in

Below is an example to illustrate:

# Allows processes in the user domain to read file type files in the script label allow user script:file {read}; # Does not allow processes in the user domain to write to file type files in the script label neverallow user script:file {write};

3.3 Configuration File

compiled by SELinuxlabelsandrulesFiles such as these will be saved in the rule of each partition:etc/selinuxThe directory below:

$ls -l system/etc/selinux drwxrwxr-x 2 root root 4096 Dec 9 15:53 mapping/ -rw-rw-r-- 1 root root 40561 Dec 10 15:56 plat_file_contexts -rw-rw-r-- 1 root root 8614 Dec 10 15:56 plat_hwservice_contexts -rw-rw-r-- 1 root root 7243 Dec 9 15:53 plat_mac_permissions.xml -rw-rw-r-- 1 root root 48646 Dec 10 15:56 plat_property_contexts -rw-rw-r-- 1 root root 1905 Dec 10 15:56 plat_seapp_contexts -rw-rw-r-- 1 root root 65 Dec 10 15:55 plat_sepolicy_and_mapping.sha256 -rw-rw-r-- 1 root root 1623615 Dec 10 15:55 plat_sepolicy.cil -rw-rw-r-- 1 root root 19798 Dec 10 15:56 plat_service_contexts -rw-rw-r-- 1 root root 818418 Dec 10 15:55 sepolicy_neverallows

Among themplat_sepolicy.cilrecords SELinux rules,plat_sepolicy_and_mapping.sha256To verify files, the rest of the files record are tag data.

Four, SEAndroid security risks

SELinux achieves the purpose of converging the attack surface and reducing losses by maximizing the restriction of the resources that service processes can access in the system; however, it is not omnipotent. Issues such as debugging interfaces left by development, kernel vulnerabilities, and incorrect strategy configurations can all lead to attackers bypassing SELinux's restrictions and attacking the system.

4.1 Custom backdoor

As the saying goes, 'The enemy is in the本能寺', some manufacturers may reserve a way to shut down SELinux for convenience during development to facilitate debugging.Backdoor interface, if suchBackdoorBefore formal release, if not deleted, it may be exploited by attackers to shut down SELinux.

4.2 Kernel Vulnerability

SELinux mainly limits user-space operations. If an attacker gains the ability to read and write any address through kernel vulnerabilities, they can overwrite global variablesselinux_enforcingmethod to disable SELinux.

For this reason, Samsung uses its self-developedRKP(Real-time Kernel Protection)mechanism, placing sensitive global variables in the protectedkdp_ro sectionto some extent mitigates such attacks.

4.3 Policy Too Broad

SELinux also existspeoplethe issues introduced, ifsensitive servicesopened to ordinary users, or forSystem APP,PropertyThe permission division is not detailed, which can lead to a wider range of impact when attacked.

4.4 Service Function and SELinux Policy Misalignment

In the Android system, some areas need to write various data frequently, such as/data/local/tmp,/sdcardetc., therefore SELinux does not impose strict restrictions on these locations, and normal user permissions can read and write the data within them.

In principle, these directories should not store sensitive data. If R&D personnel store some important files in these directories (such as configuration files, privacy information, firmware upgrades, etc.), there is a risk of being stolen or tampered with by attackers.

5. SEAndroid Disable Methods

The methods introduced above are ways to bypass SELinux at runtime, but in daily work, there is also such a scenario where we need to obtain Root permissions on an unlocked Android device for testing; there are some excellent Root tools on high-version Android, such asMagisk,KernelSUetc., but using automated tools can never fully understand the underlying principles. If you want to manually ROOT the device, disabling SELinux is a crucial step. Below are several methods for manually disabling SELinux.

5.1 Patch Boot

Download the full firmware package corresponding to the Android device, after unpacking the Boot partition, you can find the layout as follows

header # kernel runtime parameters & other information kernel # Linux kernel ramdisk.cpio # boot partition

headerThe structure is as follows, wherecmdlinewill be passed to the kernel as boot parameters, therefore we can modifycmdlinein the manner, the command to disable SELinux is passed inenforcing=0 androidboot.selinux=permissive.

cmdline= os_version=12.0.0 os_patch_level=2021-12

However, in high-version Android systems, many manufacturers no longer parsecmdlinewith poor versatility.

5.2 Patch Init

initis the first user-space process run after the Linux Kernel starts, its main function is to complete initialization, parsing and executioninit.rcThe various services defined, the process is mainly divided into four steps:

FirstStateMain->SetupSelinux->SecondStageMain->ueventd_main

Among themSetupSelinuxThe key functions at this stage are as follows:

• LoadSelinuxPolicy：Loading sepolicy strategy

• selinux_android_restorecon：Reloading sepolicy strategy

• SelinuxSetEnforcement：Set SElinux switch

It is obviously crucial thatSelinuxSetEnforcementThe function, whose internal implementation is as follows.

void SelinuxSetEnforcement() { bool kernel_enforcing = (security_getenforce() == 1); bool is_enforcing = IsEnforcing(); if (kernel_enforcing != is_enforcing) { if (security_setenforce(is_enforcing)) { PLOG(FATAL) << "security_setenforce(" << (is_enforcing ? "true" : "false") << ") failed"; } } if (auto result = WriteFile("/sys/fs/selinux/checkreqprot", "0"); !result.ok()) { LOG(FATAL) << "Unable to write to /sys/fs/selinux/checkreqprot: " << result.error(); } } bool IsEnforcing() { if (ALLOW_PERMISSIVE_SELINUX) { return StatusFromProperty() == SELINUX_ENFORCING; } return true; }

Here only Patch is neededIsEnforcingso that it always returnsFalseyou can disable it ininit stageDisable Selinux

5.3 Re-compile Kernel

based onGPLprotocol, the manufacturer will open source the modifiedLinux Kernel, so it can be disabled by recompiling the kernel during compilation.

The specific method is to set it in the kernel configuration file .configCONFIG_SECURITY_SELINUX=n.

5.4 Patch Kernel

If the manufacturer does not open source the kernel or the open source is not thorough and cannot be compiled normally, it can also bypass SELinux through the patch method

Here we takefile open operation openfor example, to sort out the related call chain of SELinux

Image source: https://blog.csdn.net/bruk_spp/article/details/107283935

When the user space callsopenWhen opening a file, a system call is triggereddo_dentry_open, then call the Linux LSM public interfacesecurity_file_open, after which it will go to the SELinux function for handling open operationsselinux_file_open, the next step SELinux will callavc public functionto implement permission checking and log auditing functions, if an operation exceeds its authority, it will callavc_deniedto prevent this behavior.

Therefore, we only need to patch the relevant logic of preventing operations to disable SElinux.

Summary

In summary, the introduction of SELinux has greatly reduced the losses caused by attacks at the user level, even if root privileges are obtained through vulnerabilities, they will be restricted within a relatively small range of impact. In recent years, with the introduction of numerous hardware and software protection mechanisms, the security of Android has been significantly improved; by using excellent and publicly available security mechanisms to converge the attack surface and enhance the security level, this is also a model for our domestic operating systems to learn from and strive to achieve.

Reference

• https://source.android.com/security/selinux
