IOSSecuritySuite： a security anti-tampering protection tool for the iOS platform

1. Detect if the system is jailbroken (supports iOS 11+);

2. Detect if a debugger is attached;

3. Determine if the application is running on a simulator;

4. Detect common reverse engineering tools running on the device;

Tool installation

Firstly, researchers need to use the following command to clone the source code of this project locally:

git clone https://github.com/securing/IOSSecuritySuite.git

We provide four methods to help researchers run and use IOSSecuritySuite.

1. Add source code

Directly add the 'IOSSecuritySuite/*.swift’ file to your project.

2. Configure using CocoaPods

pod 'IOSSecuritySuite'

3. Configure using Carthage

github "securing/IOSSecuritySuite"

4. Configure using Swift package management tools

.package(url: "https://github.com/securing/IOSSecuritySuite.git", from: "1.5.0")

Update Info.plist

After adding IOSSecuritySuite to your project, we still need to update the main Info.plist file. It contains the detection code for jailbreak detection mode, which uses the 'canOpenURL(_:)’ method and requires specifying the query URL address:

<key>LSApplicationQueriesSchemes</key>

<array>

<string>cydia</string>

<string>undecimus</string>

<string>sileo</string>

<string>zbra</string>

<string>filza</string>

<string>activator</string>

</array>

Tool Usage

Jailbreak Detection Module

The following methods will determine if the device is jailbroken and return a True or False value:

if IOSSecuritySuite.amIJailbroken() {

print("This device is jailbroken")

}

print("This device is not jailbroken")

}

Verbose Mode:

let jailbreakStatus = IOSSecuritySuite.amIJailbrokenWithFailMessage()

if jailbreakStatus.jailbroken {

print("This device is jailbroken")

print("Because: \(jailbreakStatus.failMessage)")

}

print("This device is not jailbroken")

}

The 'failMessage' is a string that contains indicators separated by commas:

Cydia URL scheme detected, Suspicious file exists: /Library/MobileSubstrate/MobileSubstrate.dylib, Fork was able to create a new process

Verbose & Data Filtering:

let jailbreakStatus = IOSSecuritySuite.amIJailbrokenWithFailedChecks()

if jailbreakStatus.jailbroken {

if (jailbreakStatus.failedChecks.contains { $0.check == .existenceOfSuspiciousFiles }) && (jailbreakStatus.failedChecks.contains { $0.check == .suspiciousFilesCanBeOpened }) {

print("This is a real jailbroken device")

}

}

调试器检测模块

let amIDebugged: Bool = IOSSecuritySuite.amIDebugged()

禁用调试器

IOSSecuritySuite.denyDebugger()

模拟器检测模块

let runInEmulator: Bool = IOSSecuritySuite.amIRunInEmulator()

逆向工程工具检测模块

let amIReverseEngineered: Bool = IOSSecuritySuite.amIReverseEngineered()

系统代理检测模块

let amIProxied: Bool = IOSSecuritySuite.amIProxied()

运行时钩子检测模块

let amIRuntimeHooked: Bool = amIRuntimeHook(dyldWhiteList: dylds, detectionClass: SomeClass.self, selector: #selector(SomeClass.someFunction), isClassMethod: false)

禁用符号钩子模块

denySymbolHook("$s10Foundation5NSLogyySS_s7CVarArg_pdtF") // 禁止对NSLog函数进行钩子操作

NSLog("Hello Symbol Hook")



denySymbolHook("abort")

abort()

MSHook检测模块

// 函数声明

func someFunction(takes: Int) -> Bool {

return false

}



// 定义函数类型：@convention(thin) 表示一个“thin”函数引用，它使用Swift调用约定，没有特殊的“self”或“context”参数。

typealias FunctionType = @convention(thin) (Int) -> (Bool)



// Getting pointer address of the function we want to verify

func getSwiftFunctionAddr(_ function: @escaping FunctionType) -> UnsafeMutableRawPointer {

return unsafeBitCast(function, to: UnsafeMutableRawPointer.self)

}



let funcAddr = getSwiftFunctionAddr(someFunction)

let amIMSHooked = IOSSecuritySuite.amIMSHooked(funcAddr)

License Agreement

The development and release of this project followBSD-2-ClauseOpen Source License Agreement.

Project address

IOSSecuritySuite：【GitHub link】

Reference materials

https://github.com/OWASP/owasp-masvs

https://www.securing.biz/

https://developer.apple.com/documentation/uikit/uiapplication/1622952-canopenurl

https://www.securing.biz/en/mobile-application-security-best-practices/index.html

https://github.com/rockbruno/swiftshield

https://github.com/TheSwiftyCoder/JailBreak-Detection

https://github.com/abhinashjain/jailbreakdetection

https://gist.github.com/ddrccw/8412847
