AtomLdr： An advanced DLL loading tool with evasion features

1. Independent CRT library;

2. The final DLL file can run the Payload by loading the DLL (executing its entry point) or by executing the exported 'Atom' function via the command line;

3. The DLL unhooks from the \KnwonDlls directory and does not have an RWX field;

4. The encrypted Payload is stored in the resource field and can be retrieved through custom code;

5. The Payload is encrypted using AES256-CBC;

6. AES key and IV encryption;

7. Indirect system calls are used with ROP gadgetsHellHall；

8. Payload injection is implemented using APC call;

9. Payload execution is implemented using APC;

10. Two different CRC32 string hash algorithms are used to implement API hash;

11. The entire tool code mentions very little;

Working mechanism

Tool download

Researchers can use the following command to clone the source code of this project locally:

git clone https://github.com/NUL0x4C/AtomLdr.git

Tool usage

1.PayloadBuilderIt needs to compile and execute with the specified Payload, which will output a PayloadConfig.pc file containing the encrypted Payload and its encryption key and IV;

2. The generated PayloadConfig.pc file needs to replace the【PayloadConfig.pc】;

3. Compile the AtomLdr project into an x64 version;

4. To enable debug mode, please select【Here】Uncomment here;

Tool usage examples

Example 1

Execute AtomLdr.dll, run rundll32.exe, runHavocPayload, the tool interface is shown as follows:

Import address table of AtomLdr.dll:

Example 2 - Debug Mode

Run PayloadBuilder.exe, encrypt demon[111].bin (a Havoc Payload file):

Run AtomLdr.dll using rundll32.exe:

After Payload execution, Havoc captures the screen shot:

license agreement

The development and release of this project followApache-2.0Open source license agreement.

Project address

AtomLdr：【GitHub Gateway】

Reference materials

https://github.com/NUL0x4C/AtomLdr/blob/main/maldevacademy.com

https://github.com/bitcoin-core/ctaes

https://github.com/Maldev-Academy/HellHall

https://www.x86matthew.com/view_post?id=writeprocessmemory_apc

https://github.com/vxunderground/VX-API

https://github.com/HavocFramework/Havoc
