About Wi-Fi Framework

The main advantage of this framework is that it allows us to reuse Linux's Wi-Fi functionality to implement security tests more easily. For example, the framework can help us connect to (protected) Wi-Fi networks and broadcast beacons for test clients. Generally, any Wi-Fi functionality of Linux can be reused to implement security tests more quickly.

Wi-Fi Framework architecture

The following figure shows the architecture of the Wi-Fi daemon and framework components in the Wi-Fi Framework:

Tool installation

This framework can run on local Linux systems or virtual machines.

Firstly, we need to use the following command to clone the project source code to the local machine:

git clone https://github.com/domienschepers/wifi-framework.git

Next, use the following command to install the dependency components required by the tool:

apt-get update

apt-get install git make gcc python3-venv net-tools

apt-get install libdbus-1-dev libnl-3-dev libnl-genl-3-dev libnl-route-3-dev libssl-dev

After installation, use the following command to install the framework:

cd https://www.freebuf.com/articles/dependencies

https://www.freebuf.com/articles/wireless/build.sh

cd https://www.freebuf.com/articles/setup

https://www.freebuf.com/articles/wireless/pysetup.sh

Libwifi

The libwifi library is used as a git submodule and needs to be manually installed:

git submodule init

git submodule update

Tool usage

Initialize and activate the Python environment:

source setup/venv/bin/activate

Simulate Wi-Fi network interface:

https://www.freebuf.com/articles/wireless/setup-hwsim.sh 4

Run the tool and create a test case:

usage: run.py [-h] [--config CONFIG] [--binary BINARY] [--debug DEBUG] iface name

Specify network configuration information:

cd setup

ln -s supplicant-wpa3-personal.conf supplicant.conf

Tool Usage Example

Assuming that we now need to test whether the client uses a zero-key to encrypt frame data, and this situation may occur during a key reinstallation attack. With the help of the Wi-Fi Framework, we do not need to reimplement all the functions of the access point, but only write the following test cases:

class ExampleKrackZerokey(Test):

name = "example-krack-zero-key"

kind = Test.Authenticator



def __init__(self):

super().__init__([

# Replay 4-Way Handshake Message 3/4.

Action( trigger=Trigger.Connected, action=Action.Function ),

# Receive all frames and search for one encrypted with an all-zero key.

Action( trigger=Trigger.NoTrigger, action=Action.Receive ),

# When we receive such a frame, we can terminate the test.

Action( trigger=Trigger.Received, action=Action.Terminate )

])





def resend(self, station):

# Resend 4-Way Handshake Message 3/4.

station.wpaspy_command("RESEND_M3 " + station.clientmac )





def receive(self, station, frame):

if frame[Dot11].addr2 != station.clientmac or not frame.haslayer(Dot11CCMP):

return False



# Check if CCMP-encrypted frame can be decrypted using an all-zero key

plaintext = decrypt_ccmp(frame.getlayer(Dot11), tk=b"\x00"*16)

if plaintext is None: return False



# We received a valid plaintext frame!

log(STATUS,'Client encrypted a frame with an all-zero key!', color="green")

return True

The above test cases will create an access point that a client can connect to. After the client connects, it will send 4 handshake messages to the client. Next, the vulnerable client will start using all-zero encryption for the key, and the test case will automatically detect this situation.

We can also use simulated Wi-Fi to run the above test cases:

https://www.freebuf.com/articles/wireless/setup/setup-hwsim.sh 4

source setup/venv/bin/activate

https://www.freebuf.com/articles/wireless/run.py wlan1 example-krack-zero-key

Project Address

Wi-Fi Framework：【GitHub Gateway】

Reference Materials

https://github.com/vanhoefm/libwifi

https://www.krackattacks.com/#demo

https://dl.acm.org/doi/10.1145/3448300.3468261

https://github.com/vanhoefm/fragattacks

https://github.com/domienschepers/wifi-framework/blob/master/docs/EXAMPLES.md
