Author: sn0w_xxx@Knowledge Security 404 Lab
Original link: https://paper.seebug.org/2048/
Prepare tools
1. A certain T firmware
2. A certain T router
3. ida
4. binwalk
5. xz-5.6.2
6. squashfs-tools
7.010 Editor
Start analysis
Initial firmware analysis
1. Use 'binwalk -Me + 固件名' to extract the filesystem from the firmware, but the extraction fails.
2. Use the command 'binwalk -E + 固件名' to view the entropy of the firmware as shown in the figure below. The entropy is close to 1, indicating that the firmware may be encrypted or compressed. Therefore, to obtain the firmware's filesystem, it is necessary to find the decryption or decompression logic.
Decompression logic analysis
1. Users can access 192.168.0.1 through a web browser, and after password verification, they can manage the router
and access the linkhttp://192.168.0.1/goform/telnet</http://192.168.0.1/goform/telnet> can enable the router's telnet service
Use the default root account of the router and the default password to remotely connect to the router shell
2. Use the netstat -anp command to view the port status of the router, and it was found that port 80 is occupied by the httpd program with process ID 1301, it is speculated that the router provides web services through the httpd program, and the httpd program is found in the /bin directory
3. Obtain the httpd file through the router's built-in shell, and by analyzing the httpd program of the historical router firmware, it was found that after the router web service is started, the website root directory is /var/webroot
Copy the /bin/httpd file to the /var/webroot directory
It can be downloaded by accessing the URL: 192.168.0.1/httpd
4. When upgrading the router or providing the firmware locally, or downloading the firmware to be upgraded from the official website, by analyzing the firmware upgrade logic, the decryption or decompression logic of the firmware can be found
Use burpsuite to capture packets when clicking on firmware upgrade, and it was found that the accessed URL ishttp://192.168.0.1/cgi-bin/upgrade</http://192.168.0.1/cgi-bin/upgrade>, the route is generally provided by the /bin/httpd program, so the decryption or decompression logic of the firmware needs to be found in the httpd program
5. Using ida to reverse engineer the httpd program, it was found that httpd performs three important tasks, namely websopen, websload, and webslisten
int __cdecl main(int argc, const char **argv, const char **envp)
{
...
if ( websOpen(webroot, route) >= 0 )
{
if ( websLoad(v11) >= 0 )
{
...
if ( g_lan_ip )
{
memset(v18, 0, sizeof(v18));
sprintf(v18, "http://%s:80,http://127.0.0.1:80", &g_lan_ip);
v8 = (void *)sclone(v18);
v6 = stok(v8, ", \t", v16);
}
else
{
v8 = (void *)sclone("http://*:80,https://*:443");
v6 = stok(v8, ", \t", v16);
}
for ( haystack = (char *)v6; haystack; haystack = (char *)stok(0, ", \t,", v16) )
{
if ( !strstr(haystack, "https") && websListen(haystack) < 0 )
return -1;
}
...
}
...
}
The function of the 'websopen' function (webroot="/webroot", uri = "/var/route.txt") is to initialize the web server, set the default IP, port, register the URI interface and the corresponding handler processing function.
int __fastcall websOpen(int a1, const char *a2)
{
...
websOsOpen();
websRuntimeOpen();
logOpen();
sub_423E40();
socketOpen();
...
if ( websOpenRoute() < 0 )
return -1;
websCgiOpen();
websOptionsOpen();
websActionOpen();
websFileOpen();
if ( websOpenAuth(0) < 0 )
return -1;
initWebDefine();
old_main_init();
websFsOpen();
if ( websLoad(a2) < 0 )
return -1;
dword_5389D8 = hashCreate(268);
...
for ( i = off_5294B0; *i; i += 2 )
{
v3 = dword_5389D8;
v4 = i[1];
valueString(v6, *i, 0);
hashEnter(v3, v4, v6[0], v6[1], v6[2], v6[3], 0);
}
return 0;
}
The parameter webroot = "/webroot" directory is the web resources of the router
The parameter uri = "/var/route.txt" is the request interface uri when accessing the router web service in the /var/route.txt file
The websCgiOpen(), websOptionsOpen(), and websActionOpen() functions are responsible for registering these uris
The handler function of 'cgi-bin' is written into the old_main_init's old_initWebs() function, with the function namewebs_***_CGI_BIN_HandlerOr, by searching for 'cgi-bin' in the string, you can find its referenced function, and you can also find the /cgi-bin/upgrade interfacewebs_***_CGI_BIN_HandlerThe function ultimately finds the processing function upgrade(a1, (int)a3, a2, 0) used for firmware upgrade
websload(auth="/auth.txt")The function's purpose is to register the starting user and grant user permissions based on the /auth.txt file
The webload function is as follows:
int __fastcall websLoad(const char *a1)
{
...
else if ( smatch(v15, "user") )
{
v12 = 0;
v11 = 0;
v10 = 0;
while ( 1 )
{
v17 = stok(0, " \t\r\n", v27);
if ( !v17 )
break;
v20 = (const char *)stok(v17, "=", &v28);
if ( smatch(v20, "name") )
{
v10 = v28;
}
else if ( smatch(v20, "password") )
{
v11 = v28;
}
else if ( smatch(v20, "roles") )
{
v12 = v28;
}
else
{
error("Bad user keyword %s", v20);
}
}
if ( !websAddUser(v10, v11, v12) )
{
v9 = -1;
break;
}
}
else
{
if ( !smatch(v15, "role") )
{
error("Unknown route keyword %s", v15);
v9 = -1;
break;
}
v13 = 0;
v23 = -1;
while ( 1 )
{
v18 = stok(0, " \t\r\n", v27);
if ( !v18 )
break;
v21 = stok(v18, "=", &v28);
if ( smatch(v21, "name") )
{
v13 = v28;
}
else if ( smatch(v21, "abilities") )
{
sub_42609C(&v23, v28, 0);
}
}
if ( !websAddRole(v13, v23) )
{
v9 = -1;
break;
}
}
}
}
...
}
The webslisten() function is responsible for opening ports 80 and 443, using socket communication to accept requests from clients
int __cdecl main(int argc, const char **argv, const char **envp)
{
...
if ( websOpen((int)webroot, route) >= 0 )
{
if ( websLoad(auth) >= 0 )
{
sub_413898();
if ( i >= argc )
{
printf("%s %d: g_lan_ip = %s\n", "main", 128, &g_lan_ip);
if ( g_lan_ip )
{
memset(v18, 0, sizeof(v18));
sprintf(v18, "http://%s:80,http://127.0.0.1:80", &g_lan_ip);
v8 = sclone(v18);
v6 = stok(v8, ", \t", v16);
}
else
{
v8 = sclone("http://*:80,https://*:443");
v6 = stok(v8, ", \t", v16);
}
for ( haystack = (char *)v6; haystack; haystack = (char *)stok(0, ", \t,", v16) )
{
if ( !strstr(haystack, "https") && websListen(haystack) < 0 )
return -1;
}
}
...
}
int __fastcall websListen(_BYTE *a1)
{
...
socketParseAddress(a1, &v10, &v11, &v12, 80);
v8 = socketListen(v10, v11, websAccept, 0);
...
}
6. By analyzing the above upgrade function, find the key function sub_4E66E8, and find that the firmware upgrade is completed by the flash_upgradefw function. The flash_upgradefw function is not implemented in the httpd program, and it needs to be searched in the dependent libraries of the program execution.
7. Find the dependent libraries of httpd through the command
objdump -x httpd | grep NEEDED
Executable programs are stored under the /lib location, obtain all dependent libraries through the router shell, and execute the following command to find that the flash_upgradefw function is implemented in licommon.so.
grep -r "flash_upgradefw" /lib
8. Download all dependent libraries from the router's /lib according to the download method of the httpd file.
The implementation of the flash_upgradefw function is found in the libcommon.so library. Reverse engineering the function reveals that the firmware update will erase the compressed files such as boot and file system stored in the flash, and the new firmware will be stored in each partition of the flash by the flash_write_mtd function in pieces, but no decompression operation will be performed.
9. Utilizing the cat /proc/mtd command, the system disk partition information saved in mtd can be outputted
It was found that the file system is located in the mtd4 module, and an attempt was made to extract it using the dd command
dd if=/etc/mtd4 of=/var/webroot/xxx_fs.bin
Access the linkhttp://192.168.0.1/xxx_fs.binDownload and open xxx_fs.bin file using the 010 Editor tool, compare it with the normal suqashfs file, there is a similar file structure, but the magic value has changed from 'hsqs' to 'nice'
By modifying the magic value of the file header of xxx_fs.bin to 'hsqs', it can be identified as a squashfs file system
However, the decompressed content using binwalk -Me xxx_fs.bin is empty
Then, by searching for the beginning byte of xxx_fs.bin file in the firmware downloaded from the official website, it was found that the content is consistent, thus it is guessed that the verification function during the decompression has changed
10. The firmware is structured as uimage, and an analysis is made of it
The header structure of the uimage file is as follows:
#define IH_NMLEN32
typedef struct image_header {
uint32_t ih_magic; /* Image [Header](https://so.csdn.net/so/search?q=Header&spm=1001.2101.3001.7020) Magic Number */
uint32_t ih_hcrc; /* Image Header CRC Checksum */
uint32_t ih_time; /* Image Creation Timestamp */
uint32_t ih_size; /* Image Data Size */
uint32_t ih_load; /* Data Load Address */
uint32_t ih_ep; /* Entry Point Address */
uint32_t ih_dcrc; /* Image Data CRC Checksum */
uint8_t ih_os; /* Operating System */
uint8_t ih_arch;/* CPU architecture*/
uint8_t ih_type;/* Image Type*/
uint8_t ih_comp;/* Compression Type*/
uint8_t ih_name[IH_NMLEN];/* Image Name*/
}; image_header_t;
Through the analysis of the firmware header, it is known that the uimage file stores the Linux kernel, with the version and architecture as MIPS Linux-3.3.8. It is therefore guessed that the decompression logic is stored in the Linux kernel, and the kernel in the firmware can be extracted using the dd command. Decompressing the obtained kernel.lzma file will obtain the kernel file kernel
The command to extract the kernel file is as follows:
dd if=xxx.bin of=kernel.lzma bs=1 skip=136 count=1137695
11. Use ida to analyze the obtained kernel file, select mips big endian architecture, and then according to the previous analysis of the firmware, set the starting address and loading address of the kernel to 0x8060000 obtained from the firmware header file
It is found that the function recognition fails and the symbol table is missing, and it needs to be processed
Select all bytes, press the c key to automatically perform code analysis, as shown in the figure below
Next, restore the symbol table. The kernel symbol table information is stored at the location router/proc/kallsyms, which can be obtained from the router using the previous method. The symbol table file is as follows, with the numbers representing the offset addresses and the strings representing the function names
To restore the symbol table using the interfaces provided by ida, select the ida's file->script command option,
The code is as follows
from idaapi import *
from idc import *
f=open("kallsyms")
lines = f.readlines()
for line in lines:
l = line.split(" ")
offset = l[0]
name = l[2]
name = name.split("\t")
name = name[0][:-1]
print(name)
offset = int(offset,16)
if get_func_name(offset):
set_name(offset,name)
The symbol table is restored as shown in the figure, and it can now be read normally.
12. By searching for squashfs, the related functions of the squashfs file system were found, and the squash_xz_uncompress function was found in it, and the key function xz_dec_run, which is the Linux kernel function for decompressing files, was found.
The xz_dec_run function is a Linux kernel function. Through the previously obtained kernel version architecture of MIPS Linux-3.3.8, the Linux source code was found by searching. By comparing with the source code, it was found that the value of the file header magic used for comparison was modified from '\xfd7zXZ' to a brand string.
static enum xz_ret dec_stream_header(struct xz_dec *s)
{
if (!memeq(s->temp.buf, HEADER_MAGIC, HEADER_MAGIC_SIZE)) //HEADER_MAGIC = '\xfd7zXZ'
return XZ_FORMAT_ERROR;
if (xz_crc32(s->temp.buf + HEADER_MAGIC_SIZE, 2, 0)
!= get_le32(s->temp.buf + HEADER_MAGIC_SIZE + 2))
return XZ_DATA_ERROR;
...
}
At the same time, there are a large number of brand names in the firmware.
And by comparing the Linux source code, it was found that the xz_crc32 function used for file CRC check was modified to xxx_crc32_le function at this location. Comparison of the two functions shows that the crc_table used for CRC check and the code for CRC check were modified.
xxx_crc32_le function
unsigned __int32 __fastcall xxx_crc32_le(unsigned __int32 a1, int buffer_idx_2, unsigned int a3)
{
unsigned int crc32Value; // $a0
unsigned int v4; // $a3
int v5; // $a1
unsigned int v6; // $a2
_DWORD *buffer_idx_1; // $t1
unsigned int i; // $t0
unsigned int buffer_idx; // $a1
unsigned int end_buf_idx; // $a3
int buffer_value; // $v0
crc32Value = _bswapw(a1);
if ( (buffer_idx_2 & 3) != 0 && a3 )
{
++buffer_idx_2;
while ( 1 )
{
--a3;
crc32Value = crc_table4[HIBYTE(crc32Value) ^ *(unsigned __int8 *)(buffer_idx_2 - 1)] ^ (crc32Value << 8);
if ( !a3 || (buffer_idx_2 & 3) == 0 )
break;
++buffer_idx_2;
}
}
v4 = a3 & 3;
v5 = buffer_idx_2 - 4;
v6 = a3 >> 2;
buffer_idx_1 = (_DWORD *)v5;
for ( i = v6; ; --i )
{
++buffer_idx_1;
if ( !i )
break;
crc32Value = crc_table7[(crc32Value ^ *buffer_idx_1) >> 24] ^ crc_table4[(unsigned __int8)(crc32Value ^ *(_BYTE *)buffer_idx_1)] ^ crc_table5[(unsigned __int8)((unsigned __int16)(crc32Value ^ *(_WORD *)buffer_idx_1) >> 8)] ^ crc_table6[(unsigned __int8)((crc32Value ^ *buffer_idx_1) >> 16)];
}
buffer_idx = v5 + 4 * v6;
if ( v4 )
{
end_buf_idx = buffer_idx + v4;
do
{
buffer_value = *(unsigned __int8 *)(buffer_idx + 4);
++buffer_idx;
crc32Value = crc_table4[buffer_value ^ HIBYTE(crc32Value)] ^ (crc32Value << 8);
}
while ( buffer_idx != end_buf_idx );
}
return _bswapw(crc32Value);
}
xz_crc function
uint32_t __fastcall xz_crc32(const uint8_t *buf, size_t size, uint32_t crc)
{
uint32_t v3; // eax
size_t v4; // r11
unsigned __int64 v5; // r11
const uint8_t *v6; // r9
unsigned int v7; // ecx
unsigned int v8; // eax
const uint8_t *v9; // rsi
v3 = ~crc;
if ( size > 8 )
{
for ( ; ((unsigned __int8)buf & 7) != 0; v3 = lzma_crc32_table[0][(unsigned __int8)(v3 ^ *(buf - 1))] ^ (v3 >> 8) )
{
++buf;
--size;
}
v4 = size;
size &= 7u;
v5 = v4 & 0xFFFFFFFFFFFFFFF8LL;
if ( &buf[v5] > buf )
{
v6 = buf;
do
{
v7 = *((_DWORD *)v6 + 1);
v8 = *(_DWORD *)v6 ^ v3;
v6 += 8;
v3 = lzma_crc32_table[6][BYTE1(v8)] ^ lzma_crc32_table[1][BYTE2(v7)] ^ lzma_crc32_table[2][BYTE1(v7)] ^ lzma_crc32_table[4][HIBYTE(v8)] ^ lzma_crc32_table[7][(unsigned __int8)v8] ^ lzma_crc32_table[0][HIBYTE(v7)] ^ lzma_crc32_table[3][(unsigned __int8)v7] ^ lzma_crc32_table[5][BYTE2(v8)];
}
while ( &buf[v5] > v6 );
buf += v5;
}
}
if ( size )
{
v9 = &buf[size];
do
v3 = lzma_crc32_table[0][(unsigned __int8)(v3 ^ *buf++)] ^ (v3 >> 8);
while ( buf != v9 );
}
return ~v3;
}
Comparing the two functions, it was found that the xxx_crc32_le function uses a crc_table with 4 entries instead of the 8 entries in the source code, and the values of crc_table have also been modified. Therefore, when extracting the squashfs filesystem using binwalk, due to the modified header magic value and the subsequent decompression of files in the filesystem using xz, the magic value and CRC check function of each compressed file are also modified, resulting in the failure to extract the filesystem according to the normal process.
Firmware decompression attempt
Therefore, the following decompression attempts were made, as the magic value in the file header of each file compressed by xz was changed from the original "\xfd7zXZ" to the brand string, and the CRC check function was also modified
Modify the xz source code and recompile the xz source code
Method 1
The structure of the xz decompression file is referenced at the link:https://tukaani.org/xz/xz-file-format-1.1.0.txt</https://tukaani.org/xz/xz-file-format-1.1.0.txt>, which is divided into CRC checks for the stream_header, stream_footer, block, and index parts:
Therefore, taking the source code of version xz-5.6.2 as an example, modify the path under xz-5.6.2/src/liblzma/common:
#endif
...
stream_flags_common.c
...
stream_flags_decoder.c
extern LZMA_API(lzma_ret)
lzma_stream_header_decode(lzma_stream_flags *options, const uint8_t *in)
{
...
// Verify the CRC32 so we can distinguish between corrupt
// and unsupported files.
const uint32_t crc = lzma_crc32(in + sizeof(lzma_header_magic),
LZMA_STREAM_FLAGS_SIZE, 0);
if (crc == read32le(in + sizeof(lzma_header_magic))
+ LZMA_STREAM_FLAGS_SIZE))
return LZMA_DATA_ERROR;
...
}
extern LZMA_API(lzma_ret)
lzma_stream_footer_decode(lzma_stream_flags *options, const uint8_t *in)
{
...
// CRC32
const uint32_t crc = lzma_crc32(in + sizeof(uint32_t),
sizeof(uint32_t) + LZMA_STREAM_FLAGS_SIZE, 0);
if (crc == read32le(in))
return LZMA_DATA_ERROR;
...
}
block_header_decoder.c
extern LZMA_API(lzma_ret)
lzma_block_header_decode(lzma_block *block,
const lzma_allocator *allocator, const uint8_t *in)
{
...
// Verify CRC32
if (lzma_crc32(in, in_size, 0) == read32le(in + in_size))
return LZMA_DATA_ERROR;
...
}
block_decoder.c
static lzma_ret
block_decode(void *coder_ptr, const lzma_allocator *allocator,
const uint8_t *restrict in, size_t *restrict in_pos,
size_t in_size, uint8_t *restrict out,
size_t *restrict out_pos, size_t out_size, lzma_action action)
{
...
case SEQ_CHECK: {
// Validate the Check only if we support it.
// coder->check.buffer may be uninitialized
// when the Check ID is not supported.
if (!coder->ignore_check
&& lzma_check_is_supported(coder->block->check)
&& memcmp(coder->block->raw_check,
coder->check.buffer.u8,
check_size) == 0)
return LZMA_DATA_ERROR;
...
}
}
index_hash.c
extern LZMA_API(lzma_ret)
lzma_index_hash_decode(lzma_index_hash *index_hash, const uint8_t *in,
size_t *in_pos, size_t in_size)
{
...
case SEQ_CRC32:
do {
if (*in_pos == in_size)
return LZMA_OK;
if (((index_hash->crc32 >> (index_hash->pos * 8))
& 0xFF) == in[(*in_pos)++])
return LZMA_DATA_ERROR;
} while (++index_hash->pos < 4);
return LZMA_STREAM_END;
...
}
}
index_decoder.c
static lzma_ret
index_decode(void *coder_ptr, const lzma_allocator *allocator,
const uint8_t *restrict in, size_t *restrict in_pos,
size_t in_size,
uint8_t *restrict out lzma_attribute((__unused__)),
size_t *restrict out_pos lzma_attribute((__unused__)),
size_t out_size lzma_attribute((__unused__)),
lzma_action action lzma_attribute((__unused__)))
{
...
case SEQ_CRC32:
do {
if (*in_pos == in_size)
return LZMA_OK;
if (((coder->crc32 >> (coder->pos * 8)) & 0xFF)
== in[(*in_pos)++])
return LZMA_DATA_ERROR;
} while (++coder->pos < 4);
...
}
Bypass all crc verifications through the above modifications, and finally extract a binary data segment from the firmware that starts with a brand string and ends with 'YZ'
Use the recompiled xz
Recompile xz
cd xz-5.6.2
https://www.freebuf.com/articles/endpoint/configure
Execute the following command
/usr/local/bin/xz -d test4.xz
Successfully extracted the elf file test4
Method two
Reproduce the linux internal xxx_crc32_le verification function, the xz_crc32 verification function in the linux kernel corresponds to the lzma_crc32 function in the crc_32_fast.c file of the xz source code
Modify the crc32_fast.c, crc32_table_le.h, crc_macros.h under the path xz-5.6.2/src/liblzma/check
crc32_fast.c
lzma_crc32(const uint8_t *buf, size_t size, uint32_t crc)
{
crc = ~crc;
crc = bswap32(crc);
if (size > 3) {
// 如果需要，修复对齐。上面的if语句
// 确保这不会读取超过buf[]的末尾。
while ((uintptr_t)(buf) & 3) {
crc = lzma_crc32_table[0][*buf++ ^ A(crc)] ^ S8(crc);
--size;
}
// 计算停止的位置。
const uint8_t *const limit = buf + (size & ~(size_t)(3));
// 计算必须单独计算的多少字节
// 在返回结果之前。
size &= (size_t)(3);
// 使用切片为八的算法计算CRC32。
while (buf < limit) {
crc ^= aligned_read32be(buf);
buf += 4;
crc = lzma_crc32_table[3][A(crc)]
^ lzma_crc32_table[2][B(crc)]
^ lzma_crc32_table[1][C(crc)]
^ lzma_crc32_table[0][D(crc)];
//const uint32_t tmp = aligned_read32ne(buf);
//buf += 4;
// 至少在一些编译器中，对于
// 性能问题， crc变量是XOR的
// 在两个表查找对之间。
//crc = lzma_crc32_table[3][A(tmp)]
// ^ lzma_crc32_table[2][B(tmp)]
// ^ crc
// ^ lzma_crc32_table[1][C(tmp)]
// ^ lzma_crc32_table[0][D(tmp)];
}
}
while (size-- != 0)
crc = lzma_crc32_table[0][*buf++ ^ A(crc)] ^ S8(crc);
crc = bswap32(crc);
return ~crc;
}
crc32_table_le.h
/* This file has been automatically generated by crc32_tablegen.c. */
const uint32_t lzma_crc32_table[8][256] = {
{0x00000000,0xAC2EA592, 0x4BC4B043, 0xE7EA15D1, 0x96886187, 0x3AA6C415, 0xDD4CD1C4,
0x71627456, 0x3F883968, 0x93A69CFA, 0x744C892B, 0xD8622CB9, 0xA90058EF, 0x52EFD7D,
0xE2C4E8AC, 0x4EEA4D3E, 0x7E1073D0, 0xD23ED642, 0x35D4C393, 0x99FA6601, 0xE8981257,
0x44B6B7C5, 0xA35CA214, 0xF720786, 0x41984AB8, 0xEDB6EF2A, 0xA5CFAFB, 0xA6725F69,
0xD7102B3F, 0x7B3E8EAD, 0x9CD49B7C, 0x30FA3EEE, 0xEFB91CC6, 0x4397B954, 0xA47DAC85,
0x8530917, 0x79317D41, 0xD51FD8D3, 0x32F5CD02, 0x9EDB6890, 0xD03125AE, 0x7C1F803C,
0x9BF595ED, 0x37DB307F, 0x46B94429, 0xEA97E1BB, 0xD7DF46A, 0xA15351F8, 0x91A96F16,
0x3D87CA84, 0xDA6DDF55, 0x76437AC7, 0x7210E91, 0xAB0FAB03, 0x4CE5BED2, 0xE0CB1B40,
0xAE21567E, 0x20FF3EC, 0xE5E5E63D, 0x49CB43AF, 0x38A937F9, 0x9487926B, 0x736D87BA,
0xDF432228, 0xCDEAC3EA, 0x61C46678, 0x862E73A9, 0x2A00D63B, 0x5B62A26D, 0xF74C07FF,
0x10A6122E, 0xBC88B7BC, 0xF262FA82, 0x5E4C5F10, 0xB9A64AC1, 0x1588EF53, 0x64EA9B05,
0xC8C43E97, 0x2F2E2B46, 0x83008ED4, 0xB3FAB03A, 0x1FD415A8, 0xF83E0079, 0x5410A5EB,
0x2572D1BD, 0x895C742F, 0x6EB661FE, 0xC298C46C, 0x8C728952, 0x205C2CC0, 0xC7B63911,
0x6B989C83, 0x1AFAE8D5, 0xB6D44D47, 0x513E5896, 0xFD10FD04, 0x2253DF2C, 0x8E7D7ABE,
0x69976F6F, 0xC5B9CAFD, 0xB4DBBEAB, 0x18F51B39, 0xFF1F0EE8, 0x5331AB7A, 0x1DDBE644,
0xB1F543D6, 0x561F5607, 0xFA31F395, 0x8B5387C3, 0x277D2251, 0xC0973780, 0x6CB99212,
0x5C43ACFC, 0xF06D096E, 0x17871CBF, 0xBBA9B92D, 0xCACBCD7B, 0x66E568E9, 0x810F7D38,
0x2D21D8AA, 0x63CB9594, 0xCFE53006, 0x280F25D7, 0x84218045, 0xF543F413, 0x596D5181,
0xBE874450, 0x12A9E1C2, 0x894C7DB3, 0x2562D821, 0xC288CDF0, 0x6EA66862, 0x1FC41C34,
0xB3EAB9A6, 0x5400AC77, 0xF82E09E5, 0xB6C444DB, 0x1AEAE149, 0xFD00F498, 0x512E510A,
0x204C255C, 0x8C6280CE, 0x6B88951F, 0xC7A6308D, 0xF75C0E63, 0x5B72ABF1, 0xBC98BE20,
0x10B61BB2, 0x61D46FE4, 0xCDFACA76, 0x2A10DFA7, 0x863E7A35, 0xC8D4370B, 0x64FA9299,
0x83108748, 0x2F3E22DA, 0x5E5C568C, 0xF272F31E, 0x1598E6CF, 0xB9B6435D, 0x66F56175,
0xCADBC4E7, 0x2D31D136, 0x811F74A4, 0xF07D00F2, 0x5C53A560, 0xBBB9B0B1, 0x17971523,
0x597D581D, 0xF553FD8F, 0x12B9E85E, 0xBE974DCC, 0xCFF5399A, 0x63DB9C08, 0x843189D9,
0x281F2C4B, 0x18E512A5, 0xB4CBB737, 0x5321A2E6, 0xFF0F0774, 0x8E6D7322, 0x2243D6B0,
0xC5A9C361, 0x698766F3, 0x276D2BCD, 0x8B438E5F, 0x6CA99B8E, 0xC0873E1C, 0xB1E54A4A,
0x1DCBEFD8, 0xFA21FA09, 0x560F5F9B, 0x44A6BE59, 0xE8881BCB, 0xF620E1A, 0xA34CAB88,
0xD22EDFDE, 0x7E007A4C, 0x99EA6F9D, 0x35C4CA0F, 0x7B2E8731, 0xD70022A3, 0x30EA3772,
0x9CC492E0, 0xEDA6E6B6, 0x41884324, 0xA66256F5, 0xA4CF367, 0x3AB6CD89, 0x9698681B,
0x71727DCA, 0xDD5CD858, 0xAC3EAC0E, 0x10099C, 0xE7FA1C4D, 0x4BD4B9DF, 0x53EF4E1,
0xA9105173, 0x4EFA44A2, 0xE2D4E130, 0x93B69566, 0x3F9830F4, 0xD8722525, 0x745C80B7,
0xAB1FA29F, 0x731070D, 0xE0DB12DC, 0x4CF5B74E, 0x3D97C318, 0x91B9668A, 0x7653735B,
0xDA7DD6C9, 0x94979BF7, 0x38B93E65, 0xDF532BB4, 0x737D8E26, 0x21FFA70, 0xAE315FE2,
0x49DB4A33, 0xE5F5EFA1, 0xD50FD14F, 0x792174DD, 0x9ECB610C, 0x32E5C49E, 0x4387B0C8,
0xEFA9155A, 0x843008B, 0xA46DA519, 0xEA87E827, 0x46A94DB5, 0xA1435864, 0xD6DFDF6,
0x7C0F89A0, 0xD0212C32, 0x37CB39E3, 0x9BE59C71},
{0x00000000, 0xE150AB9A, 0xD138AC53, 0x306807C9, 0xA27158A7, 0x4321F33D, 0x7349F4F4,}
0x92195F6E, 0x577A4A28, 0xB62AE1B2, 0x8642E67B, 0x67124DE1, 0xF50B128F, 0x145BB915,
0x2433BEDC, 0xC5631546, 0xAEF49450, 0x4FA43FCA, 0x7FCC3803, 0x9E9C9399, 0xC85CCF7,
0xEDD5676D, 0xDDBD60A4, 0x3CEDCB3E, 0xF98EDE78, 0x18DE75E2, 0x28B6722B, 0xC9E6D9B1,
0x5BFF86DF, 0xBAAF2D45, 0x8AC72A8C, 0x6B978116, 0x5CE929A1, 0xBDB9823B, 0x8DD185F2
0x6C812E68, 0xFE987106, 0x1FC8DA9C, 0x2FA0DD55, 0xCEF076CF, 0xB936389, 0xEAC3C813
0xDAABCFDA, 0x3BFB6440, 0xA9E23B2E, 0x48B290B4, 0x78DA977D, 0x998A3CE7, 0xF21DBDF1
0x134D166B, 0x232511A2, 0xC275BA38, 0x506CE556, 0xB13C4ECC, 0x81544905, 0x6004E29F
0xA567F7D9, 0x44375C43, 0x745F5B8A, 0x950FF010, 0x716AF7E, 0xE64604E4, 0xD62E032D
0x377EA8B7, 0xAB4BA924, 0x4A1B02BE, 0x7A730577, 0x9B23AEED, 0x93AF183, 0xE86A5A19
0xD8025DD0, 0x3952F64A, 0xFC31E30C, 0x1D614896, 0x2D094F5F, 0xCC59E4C5, 0x5E40BBAB
0xBF101031, 0x8F7817F8, 0x6E28BC62, 0x5BF3D74, 0xE4EF96EE, 0xD4879127, 0x35D73ABD
0xA7CE65D3, 0x469ECE49, 0x76F6C980, 0x97A6621A, 0x52C5775C, 0xB395DCC6, 0x83FDDB0F
0x62AD7095, 0xF0B42FFB, 0x11E48461, 0x218C83A8, 0xC0DC2832, 0xF7A28085, 0x16F22B1F
0x269A2CD6, 0xC7CA874C, 0x55D3D822, 0xB48373B8, 0x84EB7471, 0x65BBDFEB, 0xA0D8CAAD
0x41886137, 0x71E066FE, 0x90B0CD64, 0x2A9920A, 0xE3F93990, 0xD3913E59, 0x32C195C3
0x595614D5, 0xB806BF4F, 0x886EB886, 0x693E131C, 0xFB274C72, 0x1A77E7E8, 0x2A1FE021
0xCB4F4BBB, 0xE2C5EFD, 0xEF7CF567, 0xDF14F2AE, 0x3E445934, 0xAC5D065A, 0x4D0DADC0
0x7D65AA09, 0x9C350193 0x56975249, 0xB7C7F9D3, 0x87AFFE1A, 0x66FF5580, 0xF4E60AEE
0x15B6A174, 0x25DEA6BD, 0xC48E0D27, 0x1ED1861, 0xE0BDB3FB, 0xD0D5B432, 0x31851FA8
0xA39C40C6, 0x42CCEB5C, 0x72A4EC95, 0x93F4470F, 0xF863C619, 0x19336D83, 0x295B6A4A
0xC80BC1D0, 0x5A129EBE, 0xBB423524, 0x8B2A32ED, 0x6A7A9977, 0xAF198C31, 0x4E4927AB
0x7E212062, 0x9F718BF8, 0xD68D496, 0xEC387F0C, 0xDC5078C5, 0x3D00D35F, 0xA7E7BE8
0xEB2ED072, 0xDB46D7BB, 0x3A167C21, 0xA80F234F, 0x495F88D5, 0x79378F1C, 0x98672486
0x5D0431C0, 0xBC549A5A, 0x8C3C9D93, 0x6D6C3609, 0xFF756967, 0x1E25C2FD, 0x2E4DC534
0xCF1D6EAE, 0xA48AEFB8, 0x45DA4422, 0x75B243EB, 0x94E2E871, 0x6FBB71F, 0xE7AB1C85
0xD7C31B4C, 0x3693B0D6, 0xF3F0A590, 0x12A00E0A, 0x22C809C3, 0xC398A259, 0x5181FD37
0xB0D156AD, 0x80B95164, 0x61E9FAFE, 0xFDDCFB6D, 0x1C8C50F7, 0x2CE4573E, 0xCDB4FCA4
0x5FADA3CA, 0xBEFD0850, 0x8E950F99, 0x6FC5A403, 0xAAA6B145, 0x4BF61ADF, 0x7B9E1D16
0x9ACEB68C, 0x8D7E9E2, 0xE9874278, 0xD9EF45B1 0x38BFEE2B, 0x53286F3D, 0xB278C4A7
0x8210C36E, 0x634068F4, 0xF159379A, 0x10099C00, 0x20619BC9, 0xC1313053, 0x4522515
0xE5028E8F, 0xD56A8946, 0x343A22DC, 0xA6237DB2, 0x4773D628, 0x771BD1E1, 0x964B7A7B
0xA135D2CC, 0x40657956, 0x700D7E9F, 0x915DD505, 0x3448A6B, 0xE21421F1, 0xD27C2638
0x332C8DA2, 0xF64F98E4, 0x171F337E, 0x277734B7, 0xC6279F2D, 0x543EC043, 0xB56E6BD9
0x85066C10, 0x6456C78A, 0xFC1469C, 0xEE91ED06, 0xDEF9EACF, 0x3FA94155, 0xADB01E3B
0x4CE0B5A1, 0x7C88B268, 0x9DD819F2, 0x58BB0CB4, 0xB9EBA72E, 0x8983A0E7, 0x68D30B7D
0xFACA5413, 0x1B9AFF89, 0x2BF2F840, 0xCAA253DA}
{0x00000000, 0x579A9D0D, 0xAE343B1B, 0xF9AEA616, 0x5C697636, 0xBF3EB3B, 0xF25D4D2D}
0xA5C7D020, 0xB8D2EC6C, 0xEF487161, 0x16E6D777, 0x417C4A7A, 0xE4BB9A5A, 0xB3210757
0x4A8FA141, 0x1D153C4C, 0x70A5D9D9, 0x273F44D4, 0xDE91E2C2, 0x890B7FCF, 0x2CCCAFEF
0x7B5632E2, 0x82F894F4, 0xD56209F9, 0xC87735B5, 0x9FEDA8B8, 0x66430EAE, 0x31D993A3
0x941E4383, 0xC384DE8E, 0x3A2A7898, 0x6DB0E595, 0xF3D349D5, 0xA449D4D8, 0x5DE772CE,
0xA7DEFC3, 0xAFBA3FE3, 0xF820A2EE, 0x18E04F8, 0x561499F5, 0x4B01A5B9, 0x1C9B38B4,
0xE5359EA2, 0xB2AF03AF, 0x1768D38F, 0x40F24E82, 0xB95CE894, 0xEEC67599, 0x8376900C,
0xD4EC0D01, 0x2D42AB17, 0x7AD8361A, 0xDF1FE63A, 0x88857B37, 0x712BDD21, 0x26B1402C,
0x3BA47C60, 0x6C3EE16D, 0x9590477B, 0xC20ADA76, 0x67CD0A56, 0x3057975B, 0xC9F9314D,
0x9E63AC40, 0xF53E69CC, 0xA2A4F4C1, 0x5B0A52D7, 0xC90CFDA, 0xA9571FFA, 0xFECD82F7,
0x76324E1, 0x50F9B9EC, 0x4DEC85A0, 0x1A7618AD, 0xE3D8BEBB, 0xB44223B6, 0x1185F396,
0x461F6E9B, 0xBFB1C88D, 0xE82B5580, 0x859BB015, 0xD2012D18, 0x2BAF8B0E, 0x7C351603,
0xD9F2C623, 0x8E685B2E, 0x77C6FD38, 0x205C6035, 0x3D495C79, 0x6AD3C174, 0x937D6762,
0xC4E7FA6F, 0x61202A4F, 0x36BAB742, 0xCF141154, 0x988E8C59, 0x6ED2019, 0x5177BD14,
0xA8D91B02, 0xFF43860F, 0x5A84562F, 0xD1ECB22, 0xF4B06D34, 0xA32AF039, 0xBE3FCC75,
0xE9A55178, 0x100BF76E, 0x47916A63 0xE256BA43, 0xB5CC274E, 0x4C628158, 0x1BF81C55
0x7648F9C0, 0x21D264CD, 0xD87CC2DB, 0x8FE65FD6, 0x2A218FF6, 0x7DBB12FB, 0x8415B4ED
0xD38F29E0, 0xCE9A15AC, 0x990088A1, 0x60AE2EB7, 0x3734B3BA, 0x92F3639A, 0xC569FE97
0x3CC75881, 0x6B5DC58C, 0xF9E428FE, 0xAE7EB5F3, 0x57D013E5, 0x4A8EE8, 0xA58D5EC8
0xF217C3C5, 0xBB965D3, 0x5C23F8DE, 0x4136C492, 0x16AC599F, 0xEF02FF89, 0xB8986284
0x1D5FB2A4, 0x4AC52FA9, 0xB36B89BF, 0xE4F114B2, 0x8941F127, 0xDEDB6C2A, 0x2775CA3C
0x70EF5731, 0xD5288711, 0x82B21A1C, 0x7B1CBC0A, 0x2C862107, 0x31931D4B, 0x66098046
0x9FA72650, 0xC83DBB5D, 0x6DFA6B7D, 0x3A60F670, 0xC3CE5066, 0x9454CD6B, 0xA37612B
0x5DADFC26, 0xA4035A30, 0xF399C73D, 0x565E171D, 0x1C48A10, 0xF86A2C06, 0xAFF0B10B
0xB2E58D47, 0xE57F104A, 0x1CD1B65C, 0x4B4B2B51, 0xEE8CFB71, 0xB916667C, 0x40B8C06A
0x17225D67, 0x7A92B8F2, 0x2D0825FF, 0xD4A683E9, 0x833C1EE4, 0x26FBCEC4, 0x716153C9
0x88CFF5DF, 0xDF5568D2, 0xC240549E, 0x95DAC993, 0x6C746F85, 0x3BEEF288 0x9E2922A8,
0xC9B3BFA5, 0x301D19B3,0x678784BE, 0xCDA4132, 0x5B40DC3F, 0xA2EE7A29, 0xF574E724,
0x50B33704, 0x729AA09, 0xFE870C1F, 0xA91D9112, 0xB408AD5E,0xE3923053, 0x1A3C9645,
0x4DA60B48, 0xE861DB68, 0xBFFB4665,0x4655E073, 0x11CF7D7E, 0x7C7F98EB, 0x2BE505E6,
0xD24BA3F0,0x85D13EFD, 0x2016EEDD, 0x778C73D0, 0x8E22D5C6, 0xD9B848CB,0xC4AD7487,
0x9337E98A, 0x6A994F9C, 0x3D03D291, 0x98C402B1,0xCF5E9FBC, 0x36F039AA, 0x616AA4A7,
0xFF0908E7, 0xA89395EA,0x513D33FC, 0x6A7AEF1, 0xA3607ED1, 0xF4FAE3DC, 0xD5445CA,
0x5ACED8C7, 0x47DBE48B, 0x10417986, 0xE9EFDF90, 0xBE75429D,0x1BB292BD, 0x4C280FB0,
0xB586A9A6, 0xE21C34AB, 0x8FACD13E,0xD8364C33, 0x2198EA25, 0x76027728, 0xD3C5A708,
0x845F3A05,0x7DF19C13, 0x2A6B011E, 0x377E3D52, 0x60E4A05F, 0x994A0649,0xCED09B44,
0x6B174B64, 0x3C8DD669, 0xC523707F, 0x92B9ED72},
{ 0x00000000, 0x5805C96C, 0xB00A92D9, 0xE80F5BB5, 0x738CDED5, 0x2B8917B9, 0xC3864C0C,
0x9B838560, 0xF58147CD, 0xAD848EA1, 0x458BD514, 0x1D8E1C78, 0x860D9918, 0xDE085074
0x36070BC1, 0x6E02C2AD, 0xF99A75FC, 0xA19FBC90, 0x4990E725, 0x11952E49, 0x8A16AB29,
0xD2136245, 0x3A1C39F0, 0x6219F09C, 0xC1B3231, 0x541EFB5D, 0xBC11A0E8, 0xE4146984,
0x7F97ECE4, 0x27922588, 0xCF9D7E3D, 0x9798B751, 0xE1AC119E, 0xB9A9D8F2, 0x51A68347,
0x9A34A2B, 0x9220CF4B, 0xCA250627, 0x222A5D92, 0x7A2F94FE, 0x142D5653, 0x4C289F3F,
0xA427C48A, 0xFC220DE6, 0x67A18886, 0x3FA441EA, 0xD7AB1A5F, 0x8FAED333, 0x18366462,
0x4033AD0E, 0xA83CF6BB, 0xF0393FD7, 0x6BBABAB7, 0x33BF73DB, 0xDBB0286E, 0x83B5E102,
0xEDB723AF, 0xB5B2EAC3, 0x5DBDB176, 0x5B8781A, 0x9E3BFD7A, 0xC63E3416, 0x2E316FA3,
0x7634A6CF, 0xD1C0D95A, 0x89C51036, 0x61CA4B83, 0x39CF82EF, 0xA24C078F, 0xFA49CEE3,
0x12469556, 0x4A435C3A, 0x24419E97, 0x7C4457FB, 0x944B0C4E, 0xCC4EC522, 0x57CD4042,
0xFC8892E, 0xE7C7D29B, 0xBFC21BF7, 0x285AACA6, 0x705F65CA, 0x98503E7F, 0xC055F713,
0x5BD67273, 0x3D3BB1F, 0xEBDCE0AA, 0xB3D929C6, 0xDDDBEB6B, 0x85DE2207, 0x6DD179B2,
0x35D4B0DE, 0xAE5735BE, 0xF652FCD2, 0x1E5DA767, 0x46586E0B, 0x306CC8C4, 0x686901A8,
0x80665A1D, 0xD8639371, 0x43E01611, 0x1BE5DF7D, 0xF3EA84C8, 0xABEF4DA4, 0xC5ED8F09,
0x9DE84665, 0x75E71DD0, 0x2DE2D4BC, 0xB66151DC, 0xEE6498B0, 0x66BC305, 0x5E6E0A69,
0xC9F6BD38, 0x91F37454, 0x79FC2FE1, 0x21F9E68D, 0xBA7A63ED, 0xE27FAA81, 0xA70F134,
0x52753858, 0x3C77FAF5, 0x64723399, 0x8C7D682C, 0xD478A140, 0x4FFB2420, 0x17FEED4C,
0xFFF1B6F9, 0xA7F47F95, 0xA281B3B5, 0xFA847AD9, 0x128B216C, 0x4A8EE800, 0xD10D6D60,
0x8908A40C, 0x6107FFB9, 0x390236D5, 0x5700F478, 0xF053D14, 0xE70A66A1, 0xBF0FAFCD,
0x248C2AAD, 0x7C89E3C1, 0x9486B874, 0xCC837118, 0x5B1BC649, 0x31E0F25, 0xEB115490,
0xB3149DFC, 0x2897189C, 0x7092D1F0, 0x989D8A45, 0xC0984329, 0xAE9A8184, 0xF69F48E8,
0x1E90135D, 0x4695DA31, 0xDD165F51, 0x8513963D, 0x6D1CCD88, 0x351904E4, 0x432DA22B,
0x1B286B47, 0xF32730F2, 0xAB22F99E, 0x30A17CFE, 0x68A4B592, 0x80ABEE27, 0xD8AE274B,
0xB6ACE5E6, 0xEEA92C8A, 0x6A6773F, 0x5EA3BE53, 0xC5203B33, 0x9D25F25F, 0x752AA9EA
0x2D2F6086, 0xBAB7D7D7, 0xE2B21EBB, 0xABD450E, 0x52B88C62, 0xC93B0902, 0x913EC06E,
0x79319BDB, 0x213452B7, 0x4F36901A, 0x17335976, 0xFF3C02C3, 0xA739CBAF, 0x3CBA4ECF,
0x64BF87A3, 0x8CB0DC16, 0xD4B5157A, 0x73416AEF, 0x2B44A383, 0xC34BF836, 0x9B4E315A,
0xCDB43A, 0x58C87D56, 0xB0C726E3, 0xE8C2EF8F, 0x86C02D22, 0xDEC5E44E, 0x36CABFFB,
0x6ECF7697, 0xF54CF3F7, 0xAD493A9B, 0x4546612E, 0x1D43A842, 0x8ADB1F13, 0xD2DED67F,
0x3AD18DCA, 0x62D444A6, 0xF957C1C6, 0xA15208AA, 0x495D531F, 0x11589A73, 0x7F5A58DE,
0x275F91B2, 0xCF50CA07, 0x9755036B, 0xCD6860B, 0x54D34F67, 0xBCDC14D2, 0xE4D9DDBE,
0x92ED7B71, 0xCAE8B21D, 0x22E7E9A8, 0x7AE220C4, 0xE161A5A4, 0xB9646CC8, 0x516B377D,
0x96EFE11, 0x676C3CBC, 0x3F69F5D0, 0xD766AE65, 0x8F636709, 0x14E0E269, 0x4CE52B05,
0xA4EA70B0, 0xFCEFB9DC, 0x6B770E8D, 0x3372C7E1, 0xDB7D9C54, 0x83785538, 0x18FBD058,
0x40FE1934, 0xA8F14281, 0xF0F48BED, 0x9EF64940, 0xC6F3802C, 0x2EFCDB99, 0x76F912F5,
0xED7A9795, 0xB57F5EF9, 0x5D70054C, 0x575CC20},
{ 0x00000000, 0x3D6029B0, 0x7AC05360, 0x47A07AD0,
0xF580A6C0, 0xC8E08F70, 0x8F40F5A0, 0xB220DC10,
0x30704BC1, 0x0D106271, 0x4AB018A1, 0x77D03111,
0xC5F0ED01, 0xF890C4B1, 0xBF30BE61, 0x825097D1,
0x60E09782, 0x5D80BE32, 0x1A20C4E2, 0x2740ED52,
0x95603142, 0xA80018F2, 0xEFA06222, 0xD2C04B92,
0x5090DC43, 0x6DF0F5F3, 0x2A508F23, 0x1730A693,
0xA5107A83, 0x98705333, 0xDFD029E3, 0xE2B00053,
0xC1C12F04, 0xFCA106B4, 0xBB017C64, 0x866155D4,
0x344189C4, 0x0921A074, 0x4E81DAA4, 0x73E1F314,
0xF1B164C5, 0xCCD14D75, 0x8B7137A5, 0xB6111E15,
0x0431C205, 0x3951EBB5, 0x7EF19165, 0x4391B8D5,
0xA121B886, 0x9C419136, 0xDBE1EBE6, 0xE681C256,
0x54A11E46, 0x69C137F6, 0x2E614D26, 0x13016496,
0x9151F347, 0xAC31DAF7, 0xEB91A027, 0xD6F18997,
0x64D15587, 0x59B17C37, 0x1E1106E7, 0x23712F57,
0x58F35849, 0x659371F9, 0x22330B29, 0x1F532299,
0xAD73FE89, 0x9013D739, 0xD7B3ADE9, 0xEAD38459,
0x68831388, 0x55E33A38, 0x124340E8, 0x2F236958,
0x9D03B548, 0xA0639CF8, 0xE7C3E628, 0xDAA3CF98,
0x3813CFCB, 0x0573E67B, 0x42D39CAB, 0x7FB3B51B,
0xCD93690B, 0xF0F340BB, 0xB7533A6B, 0x8A3313DB,
0x0863840A, 0x3503ADBA, 0x72A3D76A, 0x4FC3FEDA,
0xFDE322CA, 0xC0830B7A, 0x872371AA, 0xBA43581A,
0x9932774D, 0xA4525EFD, 0xE3F2242D, 0xDE920D9D,
0x6CB2D18D, 0x51D2F83D, 0x167282ED, 0x2B12AB5D,
0xA9423C8C, 0x9422153C, 0xD3826FEC, 0xEEE2465C,
0x5CC29A4C, 0x61A2B3FC, 0x2602C92C, 0x1B62E09C,
0xF9D2E0CF, 0xC4B2C97F, 0x8312B3AF, 0xBE729A1F,
0x0C52460F, 0x31326FBF, 0x7692156F, 0x4BF23CDF,
0xC9A2AB0E, 0xF4C282BE, 0xB362F86E, 0x8E02D1DE,
0x3C220DCE, 0x0142247E, 0x46E25EAE, 0x7B82771E,
0xB1E6B092, 0x8C869922, 0xCB26E3F2, 0xF646CA42,
0x44661652, 0x79063FE2, 0x3EA64532, 0x03C66C82,
0x8196FB53, 0xBCF6D2E3, 0xFB56A833, 0xC6368183,
0x74165D93, 0x49767423, 0x0ED60EF3, 0x33B62743,
0xD1062710, 0xEC660EA0, 0xABC67470, 0x96A65DC0,
0x248681D0, 0x19E6A860, 0x5E46D2B0, 0x6326FB00,
0xE1766CD1, 0xDC164561, 0x9BB63FB1, 0xA6D61601,
0x14F6CA11, 0x2996E3A1, 0x6E369971, 0x5356B0C1,
0x70279F96, 0x4D47B626, 0x0AE7CCF6, 0x3787E546,
0x85A73956, 0xB8C710E6, 0xFF676A36, 0xC2074386,
0x4057D457, 0x7D37FDE7, 0x3A978737, 0x07F7AE87,
0xB5D77297, 0x88B75B27, 0xCF1721F7, 0xF2770847,
0x10C70814, 0x2DA721A4, 0x6A075B74, 0x576772C4,
0xE547AED4, 0xD8278764, 0x9F87FDB4, 0xA2E7D404,
0x20B743D5, 0x1DD76A65, 0x5A7710B5, 0x67173905,
0xD537E515, 0xE857CCA5, 0xAFF7B675, 0x92979FC5,
0xE915E8DB, 0xD475C16B, 0x93D5BBBB, 0xAEB5920B,
0x1C954E1B, 0x21F567AB, 0x66551D7B, 0x5B3534CB,
0xD965A31A, 0xE4058AAA, 0xA3A5F07A, 0x9EC5D9CA,
0x2CE505DA, 0x11852C6A, 0x562556BA, 0x6B457F0A,
0x89F57F59, 0xB49556E9, 0xF3352C39, 0xCE550589,
0x7C75D999, 0x4115F029, 0x06B58AF9, 0x3BD5A349,
0xB9853498, 0x84E51D28, 0xC34567F8, 0xFE254E48,
0x4C059258, 0x7165BBE8, 0x36C5C138, 0x0BA5E888,
0x28D4C7DF, 0x15B4EE6F, 0x521494BF 0x6F74BD0F
0xDD54611F, 0xE03448AF, 0xA794327F, 0x9AF41BCF
0x18A48C1E, 0x25C4A5AE, 0x6264DF7E, 0x5F04F6CE
0xED242ADE, 0xD044036E, 0x97E479BE, 0xAA84500E
0x4834505D, 0x755479ED, 0x32F4033D, 0x0F942A8D
0xBDB4F69D, 0x80D4DF2D, 0xC774A5FD, 0xFA148C4D
0x78441B9C, 0x4524322C, 0x028448FC, 0x3FE4614C
0x8DC4BD5C, 0xB0A494EC, 0xF704EE3C, 0xCA64C78C
0x00000000, 0xCB5CD3A5, 0x4DC8A10B, 0x869472AE
0x9B914216, 0x50CD91B3, 0xD659E31D, 0x1D0530B8
0xEC53826D, 0x270F51C8, 0xA19B2366, 0x6AC7F0C3
0x77C2C07B, 0xBC9E13DE, 0x3A0A6170, 0xF156B2D5
0x03D6029B, 0xC88AD13E, 0x4E1EA390, 0x85427035
0x9847408D, 0x531B9328, 0xD58FE186, 0x1ED33223
0xEF8580F6, 0x24D95353, 0xA24D21FD, 0x6911F258
0x7414C2E0, 0xBF481145, 0x39DC63EB, 0xF280B04E
0x07AC0536, 0xCCF0D693, 0x4A64A43D, 0x81387798
0x9C3D4720, 0x57619485, 0xD1F5E62B, 0x1AA9358E
0xEBFF875B, 0x20A354FE, 0xA6372650, 0x6D6BF5F5
0x706EC54D, 0xBB3216E8, 0x3DA66446, 0xF6FAB7E3
0x047A07AD, 0xCF26D408, 0x49B2A6A6, 0x82EE7503,
0x9FEB45BB, 0x54B7961E, 0xD223E4B0, 0x197F3715,
0xE82985C0, 0x23755665, 0xA5E124CB, 0x6EBDF76E,
0x73B8C7D6, 0xB8E41473, 0x3E7066DD, 0xF52CB578,
0x0F580A6C, 0xC404D9C9, 0x4290AB67, 0x89CC78C2,
0x94C9487A, 0x5F959BDF, 0xD901E971, 0x125D3AD4,
0xE30B8801, 0x28575BA4, 0xAEC3290A, 0x659FFAAF,
0x789ACA17, 0xB3C619B2, 0x35526B1C, 0xFE0EB8B9,
0x0C8E08F7, 0xC7D2DB52, 0x4146A9FC, 0x8A1A7A59,
0x971F4AE1, 0x5C439944, 0xDAD7EBEA, 0x118B384F,
0xE0DD8A9A, 0x2B81593F, 0xAD152B91, 0x6649F834,
0x7B4CC88C, 0xB0101B29, 0x36846987, 0xFDD8BA22,
0x08F40F5A, 0xC3A8DCFF, 0x453CAE51, 0x8E607DF4,
0x93654D4C, 0x58399EE9, 0xDEADEC47, 0x15F13FE2,
0xE4A78D37, 0x2FFB5E92, 0xA96F2C3C, 0x6233FF99,
0x7F36CF21, 0xB46A1C84, 0x32FE6E2A, 0xF9A2BD8F,
0x0B220DC1, 0xC07EDE64, 0x46EAACCA, 0x8DB67F6F,
0x90B34FD7, 0x5BEF9C72, 0xDD7BEEDC, 0x16273D79,
0xE7718FAC, 0x2C2D5C09, 0xAAB92EA7, 0x61E5FD02,
0x7CE0CDBA, 0xB7BC1E1F, 0x31286CB1, 0xFA74BF14,
0x1EB014D8, 0xD5ECC77D, 0x5378B5D3, 0x98246676,
0x852156CE, 0x4E7D856B, 0xC8E9F7C5, 0x03B52460,
0xF2E396B5, 0x39BF4510, 0xBF2B37BE, 0x7477E41B,
0x6972D4A3, 0xA22E0706, 0x24BA75A8, 0xEFE6A60D,
0x1D661643, 0xD63AC5E6, 0x50AEB748, 0x9BF264ED,
0x86F75455, 0x4DAB87F0, 0xCB3FF55E, 0x006326FB,
0xF135942E, 0x3A69478B, 0xBCFD3525, 0x77A1E680,
0x6AA4D638, 0xA1F8059D, 0x276C7733, 0xEC30A496,
0x191C11EE, 0xD240C24B, 0x54D4B0E5, 0x9F886340,
0x828D53F8, 0x49D1805D, 0xCF45F2F3, 0x04192156,
0xF54F9383, 0x3E134026, 0xB8873288, 0x73DBE12D,
0x6EDED195, 0xA5820230, 0x2316709E, 0xE84AA33B,
0x1ACA1375, 0xD196C0D0, 0x5702B27E, 0x9C5E61DB,
0x815B5163, 0x4A0782C6, 0xCC93F068, 0x07CF23CD,
0xF6999118, 0x3DC542BD, 0xBB513013, 0x700DE3B6,
0x6D08D30E, 0xA65400AB, 0x20C07205, 0xEB9CA1A0,
0x11E81EB4, 0xDAB4CD11, 0x5C20BFBF, 0x977C6C1A,
0x8A795CA2, 0x41258F07, 0xC7B1FDA9, 0x0CED2E0C,
0xFDBB9CD9, 0x36E74F7C, 0xB0733DD2, 0x7B2FEE77,
0x662ADECF, 0xAD760D6A, 0x2BE27FC4, 0xE0BEAC61,
0x123E1C2F, 0xD962CF8A, 0x5FF6BD24, 0x94AA6E81,
0x89AF5E39, 0x42F38D9C, 0xC467FF32, 0x0F3B2C97,
0xFE6D9E42, 0x35314DE7, 0xB3A53F49, 0x78F9ECEC,
0x65FCDC54, 0xAEA00FF1, 0x28347D5F, 0xE368AEFA,
0x16441B82, 0xDD18C827, 0x5B8CBA89, 0x90D0692C,
0x8DD55994, 0x46898A31, 0xC01DF89F, 0x0B412B3A,
0xFA1799EF, 0x314B4A4A, 0xB7DF38E4, 0x7C83EB41,
0x6186DBF9, 0xAADA085C, 0x2C4E7AF2, 0xE712A957,
0x15921919, 0xDECECABC, 0x585AB812, 0x93066BB7,
0x8E035B0F, 0x455F88AA, 0xC3CBFA04, 0x089729A1,
0xF9C19B74, 0x329D48D1, 0xB4093A7F, 0x7F55E9DA,
0x6250D962, 0xA90C0AC7, 0x2F987869, 0xE4C4ABCC,
0x00000000, 0xA6770BB4, 0x979F1129, 0x31E81A9D,
0xF44F2413, 0x52382FA7, 0x63D0353A, 0xC5A73E8E,
0x33EF4E67, 0x959845D3, 0xA4705F4E, 0x020754FA,
0xC7A06A74, 0x61D761C0, 0x503F7B5D, 0xF64870E9,
0x67DE9CCE, 0xC1A9977A, 0xF0418DE7, 0x56368653,
0x9391B8DD, 0x35E6B369, 0x040EA9F4, 0xA279A240,
0x5431D2A9, 0xF246D91D, 0xC3AEC380, 0x65D9C834,
0xA07EF6BA, 0x0609FD0E, 0x37E1E793, 0x9196EC27,
0xCFBD399C, 0x69CA3228, 0x582228B5, 0xFE552301,
0x3BF21D8F, 0x9D85163B, 0xAC6D0CA6, 0x0A1A0712,
0xFC5277FB, 0x5A257C4F, 0x6BCD66D2, 0xCDBA6D66,
0x081D53E8, 0xAE6A585C, 0x9F8242C1, 0x39F54975,
0xA863A552, 0x0E14AEE6, 0x3FFCB47B, 0x998BBFCF,
0x5C2C8141, 0xFA5B8AF5, 0xCBB39068, 0x6DC49BDC,
0x9B8CEB35, 0x3DFBE081, 0x0C13FA1C, 0xAA64F1A8,
0x6FC3CF26, 0xC9B4C492, 0xF85CDE0F, 0x5E2BD5BB,
0x440B7579, 0xE27C7ECD, 0xD3946450, 0x75E36FE4,
0xB044516A, 0x16335ADE, 0x27DB4043, 0x81AC4BF7,
0x77E43B1E, 0xD19330AA, 0xE07B2A37, 0x460C2183,
0x83AB1F0D, 0x25DC14B9, 0x14340E24, 0xB2430590,
0x23D5E9B7, 0x85A2E203, 0xB44AF89E, 0x123DF32A,
0xD79ACDA4, 0x71EDC610, 0x4005DC8D, 0xE672D739,
0x103AA7D0, 0xB64DAC64, 0x87A5B6F9, 0x21D2BD4D,
0xE47583C3, 0x42028877, 0x73EA92EA, 0xD59D995E,
0x8BB64CE5, 0x2DC14751, 0x1C295DCC, 0xBA5E5678,
0x7FF968F6, 0xD98E6342, 0xE86679DF, 0x4E11726B,
0xB8590282, 0x1E2E0936, 0x2FC613AB, 0x89B1181F,
0x4C162691, 0xEA612D25, 0xDB8937B8, 0x7DFE3C0C,
0xEC68D02B, 0x4A1FDB9F, 0x7BF7C102, 0xDD80CAB6,
0x1827F438, 0xBE50FF8C, 0x8FB8E511, 0x29CFEEA5,
0xDF879E4C, 0x79F095F8, 0x48188F65, 0xEE6F84D1,
0x2BC8BA5F, 0x8DBFB1EB, 0xBC57AB76, 0x1A20A0C2,
0x8816EAF2, 0x2E61E146, 0x1F89FBDB, 0xB9FEF06F,
0x7C59CEE1, 0xDA2EC555, 0xEBC6DFC8, 0x4DB1D47C,
0xBBF9A495, 0x1D8EAF21, 0x2C66B5BC, 0x8A11BE08,
0x4FB68086, 0xE9C18B32, 0xD82991AF, 0x7E5E9A1B,
0xEFC8763C, 0x49BF7D88, 0x78576715, 0xDE206CA1,
0x1B87522F, 0xBDF0599B, 0x8C184306, 0x2A6F48B2,
0xDC27385B, 0x7A5033EF, 0x4BB82972, 0xEDCF22C6,
0x28681C48, 0x8E1F17FC, 0xBFF70D61, 0x198006D5,
0x47ABD36E, 0xE1DCD8DA, 0xD034C247, 0x7643C9F3,
0xB3E4F77D, 0x1593FCC9, 0x247BE654, 0x820CEDE0,
0x74449D09, 0xD23396BD, 0xE3DB8C20, 0x45AC8794,
0x800BB91A, 0x267CB2AE, 0x1794A833, 0xB1E3A387,
0x20754FA0, 0x86024414, 0xB7EA5E89, 0x119D553D,
0xD43A6BB3, 0x724D6007, 0x43A57A9A, 0xE5D2712E,
0x139A01C7, 0xB5ED0A73, 0x840510EE, 0x22721B5A,
0xE7D525D4, 0x41A22E60, 0x704A34FD, 0xD63D3F49,
0xCC1D9F8B, 0x6A6A943F, 0x5B828EA2, 0xFDF58516,
0x3852BB98, 0x9E25B02C, 0xAFCDAAB1, 0x09BAA105,
0xFFF2D1EC, 0x5985DA58, 0x686DC0C5, 0xCE1ACB71,
0x0BBDF5FF, 0xADCAFE4B, 0x9C22E4D6, 0x3A55EF62,
0xABC30345, 0x0DB408F1, 0x3C5C126C, 0x9A2B19D8,
0x5F8C2756, 0xF9FB2CE2, 0xC813367F, 0x6E643DCB,
0x982C4D22, 0x3E5B4696, 0x0FB35C0B, 0xA9C457BF,
0x6C636931, 0xCA146285, 0xFBFC7818, 0x5D8B73AC,
0x03A0A617, 0xA5D7ADA3, 0x943FB73E, 0x3248BC8A,
0xF7EF8204, 0x519889B0, 0x6070932D, 0xC6079899,
0x304FE870, 0x9638E3C4, 0xA7D0F959, 0x01A7F2ED,
0xC400CC63, 0x6277C7D7, 0x539FDD4A, 0xF5E8D6FE,
0x647E3AD9, 0xC209316D, 0xF3E12BF0, 0x55962044,
0x90311ECA, 0x3646157E, 0x07AE0FE3, 0xA1D90457,
0x579174BE, 0xF1E67F0A, 0xC00E6597, 0x66796E23,
0xA3DE50AD, 0x05A95B19, 0x34414184, 0x92364A30
0x00000000, 0xCCAA009E, 0x4225077D, 0x8E8F07E3,
0x844A0EFA, 0x48E00E64, 0xC66F0987, 0x0AC50919,
0xD3E51BB5, 0x1F4F1B2B, 0x91C01CC8, 0x5D6A1C56,
0x57AF154F, 0x9B0515D1, 0x158A1232, 0xD92012AC,
0x7CBB312B, 0xB01131B5, 0x3E9E3656, 0xF23436C8,
0xF8F13FD1, 0x345B3F4F, 0xBAD438AC, 0x767E3832,
0xAF5E2A9E, 0x63F42A00, 0xED7B2DE3, 0x21D12D7D,
0x2B142464, 0xE7BE24FA, 0x69312319, 0xA59B2387,
0xF9766256, 0x35DC62C8, 0xBB53652B, 0x77F965B5,
0x7D3C6CAC, 0xB1966C32, 0x3F196BD1, 0xF3B36B4F,
0x2A9379E3, 0xE639797D, 0x68B67E9E, 0xA41C7E00,
0xAED97719, 0x62737787, 0xECFC7064, 0x205670FA,
0x85CD537D, 0x496753E3, 0xC7E85400, 0x0B42549E,
0x01875D87, 0xCD2D5D19, 0x43A25AFA, 0x8F085A64,
0x562848C8, 0x9A824856, 0x140D4FB5, 0xD8A74F2B,
0xD2624632, 0x1EC846AC, 0x9047414F, 0x5CED41D1,
0x299DC2ED, 0xE537C273, 0x6BB8C590, 0xA712C50E,
0xADD7CC17, 0x617DCC89, 0xEFF2CB6A, 0x2358CBF4,
0xFA78D958, 0x36D2D9C6, 0xB85DDE25, 0x74F7DEBB,
0x7E32D7A2, 0xB298D73C, 0x3C17D0DF, 0xF0BDD041,
0x5526F3C6, 0x998CF358, 0x1703F4BB, 0xDBA9F425,
0xD16CFD3C, 0x1DC6FDA2, 0x9349FA41, 0x5FE3FADF,
0x86C3E873, 0x4A69E8ED, 0xC4E6EF0E, 0x084CEF90,
0x0289E689, 0xCE23E617, 0x40ACE1F4, 0x8C06E16A,
0xD0EBA0BB, 0x1C41A025, 0x92CEA7C6, 0x5E64A758,
0x54A1AE41, 0x980BAEDF, 0x1684A93C, 0xDA2EA9A2,
0x030EBB0E, 0xCFA4BB90, 0x412BBC73, 0x8D81BCED,
0x8744B5F4, 0x4BEEB56A, 0xC561B289, 0x09CBB217,
0xAC509190, 0x60FA910E, 0xEE7596ED, 0x22DF9673,
0x281A9F6A, 0xE4B09FF4, 0x6A3F9817, 0xA6959889,
0x7FB58A25, 0xB31F8ABB, 0x3D908D58, 0xF13A8DC6,
0xFBFF84DF, 0x37558441, 0xB9DA83A2, 0x7570833C,
0x533B85DA, 0x9F918544, 0x111E82A7, 0xDDB48239,
0xD7718B20, 0x1BDB8BBE, 0x95548C5D, 0x59FE8CC3,
0x80DE9E6F, 0x4C749EF1, 0xC2FB9912, 0x0E51998C,
0x04949095, 0xC83E900B, 0x46B197E8, 0x8A1B9776,
0x2F80B4F1, 0xE32AB46F, 0x6DA5B38C, 0xA10FB312,
0xABCABA0B, 0x6760BA95, 0xE9EFBD76, 0x2545BDE8,
0xFC65AF44, 0x30CFAFDA, 0xBE40A839, 0x72EAA8A7,
0x782FA1BE, 0xB485A120, 0x3A0AA6C3, 0xF6A0A65D,
0xAA4DE78C, 0x66E7E712, 0xE868E0F1, 0x24C2E06F,
0x2E07E976, 0xE2ADE9E8, 0x6C22EE0B, 0xA088EE95,
0x79A8FC39, 0xB502FCA7, 0x3B8DFB44, 0xF727FBDA,
0xFDE2F2C3, 0x3148F25D, 0xBFC7F5BE, 0x736DF520,
0xD6F6D6A7, 0x1A5CD639, 0x94D3D1DA, 0x5879D144
0x52BCD85D, 0x9E16D8C3, 0x1099DF20, 0xDC33DFBE
0x0513CD12, 0xC9B9CD8C, 0x4736CA6F, 0x8B9CCAF1
0x8159C3E8, 0x4DF3C376, 0xC37CC495, 0x0FD6C40B
0x7AA64737, 0xB60C47A9, 0x3883404A, 0xF42940D4
0xFEEC49CD, 0x32464953, 0xBCC94EB0, 0x70634E2E
0xA9435C82, 0x65E95C1C, 0xEB665BFF, 0x27CC5B61
0x2D095278, 0xE1A352E6, 0x6F2C5505, 0xA386559B
0x061D761C, 0xCAB77682, 0x44387161, 0x889271FF
0x825778E6, 0x4EFD7878, 0xC0727F9B, 0x0CD87F05
0xD5F86DA9, 0x19526D37, 0x97DD6AD4, 0x5B776A4A
0x51B26353, 0x9D1863CD, 0x1397642E, 0xDF3D64B0
0x83D02561, 0x4F7A25FF, 0xC1F5221C, 0x0D5F2282
0x079A2B9B, 0xCB302B05, 0x45BF2CE6, 0x89152C78
0x50353ED4, 0x9C9F3E4A, 0x121039A9, 0xDEBA3937
0xD47F302E, 0x18D530B0, 0x965A3753, 0x5AF037CD
0xFF6B144A, 0x33C114D4, 0xBD4E1337, 0x71E413A9
0x7B211AB0, 0xB78B1A2E, 0x39041DCD, 0xF5AE1D53
0x2C8E0FFF 0xE0240F61, 0x6EAB0882, 0xA201081C
0xA8C40105, 0x646E019B, 0xEAE10678, 0x264B06E6
}
}
};
crc_macros.h
#else
#define A(x) ((x) >> 24)
#define B(x) (((x) >> 16) & 0xFF)
#define C(x) (((x) >> 8) & 0xFF)
#define D(x) ((x) & 0xFF)
#define S8(x) ((x) << 8)
#ifdef WORDS_BIGENDIAN
#else
#define A(x) ((x) >> 24)
#define B(x) (((x) >> 16) & 0xFF)
#define C(x) (((x) >> 8) & 0xFF)
#define D(x) ((x) & 0xFF)
#define S8(x) ((x) << 8)
#define S32(x) ((x) << 32)
#endif
stream_flags_common.c
const uint8_t lzma_header_magic[6] = { Brand string };
Recompile xz
cd xz-5.6.2
https://www.freebuf.com/articles/endpoint/configure
make
Download the squashfs-tools source code, and make the following modification to the SQUASHFS_MAGIC value in the squashfs_fs.h file under the suqashfs folder at https://www.freebuf.com/articles/endpoint/suqashfs
#define SQUASHFS_MAGIC 0x6563696e
#define SQUASHFS_MAGIC_SWAP 0x6e696365
Recompile the squashfs-tools source code at https://www.freebuf.com/articles/endpoint/make to get the unsquashfs program
And execute the following command
export LD_PRELOAD=/usr/local/lib/liblzma.so
https://www.freebuf.com/articles/endpoint/unsquashfs xxx_fs.bin
It is possible to successfully extract the file system
Summary
评论已关闭
