After studying, we classify the aforementioned AMSI components according to the documents provided by Microsoft：

1, User Account Control (UAC)

2, PowerShell (scripts, interactive use, and dynamic code calculation)

3, Windows Script Host (wscript.exe and cscript.exe)

4, JavaScript and VBScript

5, Office VBA macros

For engineers and defenders engaged in security defense detection, as well as for attack researchers interested in mature evasion techniques, I have raised the following questions for everyone:

1, Which actual PE files are associated with the components supported by AMSI?

2, Is the information provided by Microsoft accurate, or are there any missing components in the above list?

3, Can AMSI be used without registering the AMSI program as a terminal security provider?

AMSI component enumeration

To solve the first two problems, we need to figure out a way to automatically identify and discover AMSI components. The entire process involves a series of EXE or DLL files that contain the ASCII or Unicode string 'amsi.dll'. So why search for the 'amsi.dll' string?

1, amsi.dll can provide functions required for scanning buffer, that isAmsiScanBuffer,AmsiScanStringand AmsiUacScan.

2, This string means that EXE or DLL will be statically imported (for example, it can be stored in the PE file in the form of an ASCII string) or dynamically loaded at runtime (for example, it can be stored in the PE file in the form of a Unicode string) as amsi.dll.

The following PowerShell code may help answer our questions:

$UserPEs = Get-CimInstance -ClassName CIM_DataFile -Filter 'Drive = "C:" and (Extension = "exe" or Extension = "dll")' -Property 'Name' | Select -ExpandProperty Name
$AMSIReferences1 = $UserPEs | % { Select-String -Encoding ascii -LiteralPath $_ -Pattern 'amsi\.dll' }
$AMSIReferences2 = $UserPEs | % { Select-String -Encoding unicode -LiteralPath $_ -Pattern 'amsi\.dll' }
$AMSIReferences1.Path
$AMSIReferences2.Path

The above PowerShell code snippet uses WMI to enumerate all EXE and DLL files. The reason for choosing this method over Get-ChildItem is that it may throw exceptions when trying to access files it does not have permission to access.

Next, it will use Select-String (equivalent to grep in PowerShell) to scan each file and search for ASCII and Unicode text strings - 'amsi.dll' within the files.

After filtering the results, the following AMSI components were found:

1, %windir%\System32\consent.exe

2, %windir%\System32\jscript.dll

3, %windir%\System32\vbscript.dll

4, %windir%\System32\wbem\fastprox.dll

5, %windir%\Microsoft.NET\assembly\GAC_MSIL\System.Management.Automation\v4.0_3.0.0.0__31bf3856ad364e35\System.Management.Automation.dll

6, %windir%\Microsoft.NET\Framework64\v4.0.30319\clr.dll

7, %ProgramFiles%\WindowsApps\Microsoft.Office.Desktop_16051.11929.20300.0_x86__8wekyb3d8bbwe\VFS\ProgramFilesCommonX86\Microsoft Shared\VBA\VBA7.1\VBE7.DLL

After studying, we classify the aforementioned AMSI components according to the documents provided by Microsoft:

1, User Account Control: consent.exe

2, PowerShell: System.Management.Automation.dll

3, JavaScript and VBScript: jscript.dll, vbscript.dll

4, Office VBA Macro: VBE7.dll

5, Unclassified: clr.dll, fastprox.dll

So, what are these unclassified AMSI components? 'clr.dll', which is the Common Language Runtime, mentioned by Microsoft in .NET 4.8, scans the compiled loads in memory. Researchers are already studying related bypass mechanisms, see the references at the end of this article. Next, we will analyze 'fastprox.dll', please be patient.

WMI and AMSI

The 'fastprox.dll' is located in the 'System32\wbem' directory, and the description of 'fastprox.dll' is 'WMI Custom Marshaller', which is self-explanatory and clearly related to WMI. To further verify, we can use PowerShell to identify which process the 'fastprox.dll' is loaded with:

> Get-Process | Where-Object { $_.Modules.ModuleName -contains 'fastprox.dll' }
Handles NPM(K)   PM(K)    WS(K)    CPU(s)    Id  SI ProcessName
-------  ------   -----    -----   ------   ----  -- -----------
   2196    274    219988    232044    14,573.92    1192     5 chrome
   1162    47    85544    38524     803.86    14580     5 mmc
    692    42    129920    55564     1,081.20    2408     5 powershell
    874    47    77144    87852     73.48    4040     5 powershell
    686    39    71132    42608     42.78    12620     5 powershell
    229    13    2596     10072     0.13    2956     0 svchost
    480    20    3840     6728     69.66    3376     0 svchost
    613    34    26776    17356    4,370.64    3648     0 svchost
    217    43    2572     4148     18.64    6728     0 svchost
    564    33    11276    16544     4.34    11520    0 svchost
    129     7    1496     2196     0.77    5232     0 unsecapp
   1650    67    318004    256536    99.28    16576    5 vmconnect
    898    29    62664    23660    1,267.36    4776    0 vmms
    386    16    8492    13408    21.77    14220    0 WmiPrvSE
    176    10    2684    8592    1.36    15772    0 WmiPrvSE

We can use the following PowerShell command to parse the services corresponding to the svchost.exe process:

> Get-Process | Where-Object { $_.Modules.ModuleName -contains 'fastprox.dll' -and $_.ProcessName -eq 'svchost' } | ForEach-Object { Get-CimInstance -ClassName Win32_Service -Filter "ProcessId = $($_.Id)" } | Format-Table -AutoSize
ProcessId Name       StartMode State   Status ExitCode
--------- ----   --------- -----   ------ --------
2956   Netman     Manual    Running OK   0
3376   iphlpsvc    Auto    Running OK   0
3648   Winmgmt    Auto    Running OK   0
6728   SharedAccess Manual   Running OK   0
11520   BITS       Auto    Running OK   0

It seems that any process that wants to interact with WMI needs to use this DLL. Now, we directly examine the code to determine how fastprox.dll interacts with amsi.dll. Currently, the only 'amsi.dll' reference appears in the JAmsi::JAmsiInitialize function, and the following is the relevant code:

Firstly, the AMSI will be initialized only when the current process is not %windir%\System32\wbem\wmiprvse.exe. After calling loadlibrary in amsi.dll and parsing the required related export functions (such as amsiscanbuffer), we find that the unique cross-reference of amsiscanbuffer is the JAmsi::JAmsiRunScanner function:

JAmsiRunScanner is called by JAmsi::JAmsiProcessor, and this function will be called by the following functions:

1, CWbemSvcWrapper::XWbemServices::ExecNotificationQueryAsync
2, CWbemSvcWrapper::XWbemServices::CreateInstanceEnum
3, CWbemSvcWrapper::XWbemServices::ExecQueryAsync
4, CWbemSvcWrapper::XWbemServices::ExecQuery
5, CWbemSvcWrapper::XWbemServices::CreateInstanceEnumAsync
6, CWbemSvcWrapper::XWbemServices::GetObjectW
7, CWbemSvcWrapper::XWbemServices::ExecMethod
8, CWbemSvcWrapper::XWbemServices::ExecMethodAsync
9, CWbemSvcWrapper::XWbemServices::ExecNotificationQuery
10, CWbemSvcWrapper::XWbemServices::GetObjectAsync
11, JAmsi::JAmsiProcessor (called by CWbemInstance::SetPropValue)

Except for the last function, the other functions correspond toIWbemServices interfaceThe method implemented, while the last function is likely to correspond toIWbemClassObject::PutMethod.

Next, we need to run logman to capture all AMSI events and try to capture related WMI events:

logman start trace AMSITrace -p Microsoft-Antimalware-Scan-Interface (Event1) -o amsi.etl -ets

Next, run the following code to trigger the event test:

$CimSession = New-CimSession -ComputerName .
Invoke-CimMethod -ClassName Win32_Process -MethodName Create -Arguments @{CommandLine = 'notepad.exe'} -CimSession $CIMSession
$CIMSession | Remove-CimSession

The above command can create a local CIM session to enumerate remote WMI connections, stop event capture after completing WMI interaction:

logman stop AMSITrace -ets

Next, use PowerShell to identify any WMI events:

> $AMSIEvents = Get-WinEvent -Path .\amsi.etl -Oldest
> $AMSIEvents[5] | Format-List *
Message: AmsiScanBuffer
Id: 1101
Version: 0
Qualifiers:
Level: 4
Task: 0
Opcode: 0
Keywords: -9223372036854775807
RecordId: 5
ProviderName: Microsoft-Antimalware-Scan-Interface
ProviderId: 2a576b87-09a7-520e-c21a-4942f0271d67
LogName:
ProcessId: 7184
ThreadId: 8708
MachineName: COMPY486
UserId:
TimeCreated: 10/3/2019 12:14:51 PM
ActivityId: 95823c06-72e6-0000-a133-8395e672d501
RelatedActivityId    :
ContainerLog       : c:\users\testuser\desktop\amsi.etl
MatchedQueryIds    : {}
Bookmark           : System.Diagnostics.Eventing.Reader.EventBookmark
LevelDisplayName    : Information
OpcodeDisplayName    : Info
TaskDisplayName    :
KeywordsDisplayNames : {}
Properties         : {System.Diagnostics.Eventing.Reader.EventProperty, System.Diagnostics.Eventing.Reader.EventProperty...}
> $AMSIEvents[5].Properties
Value
-----
0
1
1
WMI
300
300
{67, 0, 73, 0...}
{131, 136, 119, 209...}
False
> [Text.Encoding]::Unicode.GetString($AMSIEvents[5].Properties[7].Value)
CIM_RegisteredSpecification.CreateInstanceEnum();
Win32_Process.GetObjectAsync();
Win32_Process.GetObject();
SetPropValue.CommandLine("notepad.exe");
> Get-CimInstance -ClassName Win32_Service -Filter "ProcessId = $($AMSIEvents[5].ProcessId)"
ProcessId Name  StartMode State   Status ExitCode
--------- ----  --------- -----   ------ --------
7184    WinRM Auto    Running OK    0

Firstly, the sixth event (index 5) is the only one that contains the attribute value “wmi” among the four attribute values. Additionally, the eighth attribute value contains binary data that looks like a Unicode string. After decoding, it reflects the execution of win32_process create in the above example. It is worth noting that the recorded process ID-7184 is the source of the AMSI event, which is a svchost.exe process.

WMI is very “messy”, the operating system regularly uses WMI for legitimate operations, and suspicious operations also involve WMI, and many WMI operations are not recorded. The reason behind this is obvious, because only when JAmsi::JAmsiIsScannerNeeded returns TRUE, JAmsi::JAmsiRunScanner will execute.

The operation context string of WMI has a specially calculated CRC checksum, and only when the checksum matches the value in the whitelist will the WMI event be recorded:

During the research process, we found that the whitelist contains the following CRC checksums:

0x788c9917, 0x96b23e8a, 0xb8da804e, 0xc0b29b3d, 0xd16f4088, 0xd61d2ea7, 0xef726924, 0x46b9d093, 0xf837efc3

It is obvious that as long as the attacker can recover the checksum in the whitelist, they can bypass the operating system's records of WMI operations. The next result, I believe everyone knows!

Summary

The method introduced in this article can be used to identify AMSI components, study their implementation (using WMI as an example), and infer context based on AMSI ETW events. This method is very effective for attackers trying to bypass AMSI detection.

Reference materials

1、https://twitter.com/mattifestation/status/1071034781020971009

2、https://modexp.wordpress.com/2019/06/03/disable-amsi-wldp-dotnet/

3、https://twitter.com/_xpn_/status/1069759374984429568

4、https://thewover.github.io/Apple-Fritter/
