How to use Dumpscan to scan and parse kernel and memory Dump data

1. Support for parsing x509 public and private keys (PKCS #8/PKCS #1);

2. SupportSymCryptParsing;

3. Support extracting and parsing environment variables;

4. Support running the tool with command line parameters to control the tool's operation;

Tool components

volatility3
construct
yara-python
typer
rich
rich_click

Tool installation

We recommend that researchers widely usepipxTo install Dumpscan:

pipx install dumpscan

pipx inject dumpscan git+https://github.com/volatilityfoundation/volatility3#39e812a

Tool usage

Usage: dumpscan [OPTIONS] COMMAND [ARGS]...



Scan memory dumps for secrets and keys



╭─ Options ────────────────────────────────────────────────────────────────────────────────────────╮

│                                                                                                │

│  --help       Display help information and exit                                                    │

│                                                                                                │

╰──────────────────────────────────────────────────────────────────────────────────────────────────╯

╭─ Commands ───────────────────────────────────────────────────────────────────────────────────────╮

│                                                                                                │

│  kernel      Use volatility to scan kernel dump                                                  │

│  minidump    Scan user mode minidump                                                          │

││

╰──────────────────────────────────────────────────────────────────────────────────────────────────╯

For subcommands that can extract certificates, we can use the "--output/-o <dir>" option to specify the directory where the scanned certificates will be extracted.

Kernel mode

The kernel analysis function implemented by this tool is achieved through Volatility3, the "cmdline", "envar", and "pslist" commands will directly call Volatility3 plugins, while "symcrypt" and "x509" are custom plugins:

Usage: dumpscan kernel [OPTIONS] COMMAND [ARGS]...



Scan kernel dump using volatility



╭─ Options ────────────────────────────────────────────────────────────────────────────────────────╮

│

│  --help       Display help information and exit

│

╰──────────────────────────────────────────────────────────────────────────────────────────────────╯

╭─ Commands ───────────────────────────────────────────────────────────────────────────────────────╮

│

│  cmdline    Enumerate process command line information (only supported on Windows)

│  envar    Enumerate process environment variables (only supported on Windows)

│  pslist    Enumerate all processes and corresponding command line parameters

│  symcrypt    Scan SymCrypt objects in kernel mode dump

│  x509    Scan x509 certificates in kernel mode dump

│

╰──────────────────────────────────────────────────────────────────────────────────────────────────╯

Minidump mode

This tool also supports Windows Minidump format, but this feature has only been tested on 64-bit processes of Windows 10+, and 32-bit processes may require additional processing.

Usage: dumpscan minidump [OPTIONS] COMMAND [ARGS]...



Scan a user-mode minidump



╭─ Options ────────────────────────────────────────────────────────────────────────────────────────╮

│

│  --help    Display help information and exit

│

│

╰──────────────────────────────────────────────────────────────────────────────────────────────────╯

╭─ Commands ───────────────────────────────────────────────────────────────────────────────────────╮

│

│  cmdline    Export command line strings

│

│  envar    Export environment variables

│  symcrypt    Scan symcrypt objects in minidump

│  x509    Scan x509 objects in minidump

│

╰──────────────────────────────────────────────────────────────────────────────────────────────────╯
