AutoGadgetFS： A security testing tool for USB devices

Easily find, select, and connect to USB devices.

Simulate any USB HID device.

Execute AGFS sniffing HID devices as middleware devices (save communication to disk).

Device sniffing (any device).

Multiple Fuzzer allows you to perform fuzz testing on devices or hosts.

Random Fuzzer (with fixed or random packet lengths).

Intelligent Fuzzer, which can learn from previous USB communications.

Tell the Fuzzer which bytes to fuzz, leaving the rest of the packet unchanged.

Mini Fuzzer.

Sequential Fuzzer.

Control the transmission enumerator.

Replay data packets from the file.

Replay data packets captured by USBLyzer from the saved file.

Display data packets in a visual way for reverse analysis of communication information.

Device alerts in DFU mode, or device leak information.

Support remote debugging for USB devices and hosts.

Monitor sudden interface changes.

Tool requirements

A host running Linux (Debian/Ubuntu/Kali);
Raspberry Pi Zero with WiFi access support;
Target device selection: virtual machine or single host;
Two USB cables;
Target USB device;
Hardware debugger (optional);

Tool configuration diagram

Device testing

Set up the middleware

Set up the middleware and support device debugging

Tool installation

Linux device

sudo apt install python3 ipython3 git python3-pip rabbitmq-server dfu-util

sudo service rabbitmq-server start

git clone https://github.com/ehabhussein/AutoGadgetFS

cd AutoGadgetFS

sudo -H pip3 install -r requirements.txt

sudo python3 -m pip install prompt-toolkit~=2.0

sudo rabbitmq-plugins enable rabbitmq_management

http://localhost:15672/ to reach the web interface

sudo rabbitmqctl add_user autogfs usb4ever

sudo rabbitmqctl set_user_tags autogfs administrator

sudo service rabbitmq-server restart

After installation, please test the installation results as follows

sudo ipython3

Python 3.7.7 (default, Apr 1 2020, 13:48:52)

Type 'copyright', 'credits' or 'license' for more information

IPython 7.9.0 -- An enhanced Interactive Python. Type '?' for help.

In [1]: import libagfs

In [2]: x = libagfs.agfs()

***************************************

AutoGadgetFS: Make USB testing easy

***************************************

Enter the IP address of the rabbitmq server: 127.0.0.1

In [3]: exit

sudo `python3` agfsconsole.py

***************************************

AutoGadgetFS: Make USB testing easy

***************************************

Enter the IP address of the rabbitmq server: 127.0.0.1

Give your project a name?!:

Tool operation screenshot

Man-in-the-middle attack

USB device fuzz testing

Host-based fuzz testing based on code coverage

Byte-based fuzz testing

AutoGadgetFS command-line terminal

Intelligent Fuzzer based on traffic learning

In [44]: x.devSmartFuzz(engine="smart",samples=5,filename="/home/raindrop/PycharmProjects/AutoGadgetFs/binariesdb/Nud-Nuvoton-1046-20764-1590421333.5169587-Nuvoton-1046-20764-1590421600.8067

...: 274-device.bin"

[+]General Statistics

Full charset: !"#$%&'()*+,-https://www.freebuf.com/articles/endpoint/0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`abcdefghijklmnopqrstuvwxyz{|}~

Discarded charset: !"#$%&'()*+,-https://www.freebuf.com/articles/endpoint/:;<=>?@ABCDEFGHIJKLMNOPQRSTUVWXYZ[\]^_`abcdefghijklmnopqrstuvwxyz{|}~

Final charset: 0123456789abcdef

Word Length: 128

Lower Case index usage: 92%

Lower Case index locations: [1, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 70, 71, 72, 73, 74, 75, 76, 77, 78, 79, 80, 81, 82, 83, 84, 85, 86, 87, 88, 89, 90, 91, 92, 93, 94, 95, 96, 97, 98, 99, 100, 101, 102, 103, 104, 105, 106, 107, 108, 109, 110, 111, 112, 113, 114, 115, 121, 122, 124, 125, 127

Upper Case index usage: 0%

Upper Case index locations: []

Digit index usage: 96%

Digit index locations: [0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18, 19, 20, 21, 22, 23, 24, 25, 26, 27, 28, 29, 30, 31, 32, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54, 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67, 68, 69, 70, 71, 72, 73, 74, 75, 76, 77, 78, 79, 80, 81, 82, 83, 84, 85, 86, 87, 88, 89, 90, 91, 92, 93, 94, 95, 96, 97, 98, 99, 100, 101, 102, 103, 104, 105, 106, 107, 108, 109, 110, 111, 112, 113, 114, 115, 116, 117, 118, 119, 120, 123, 126]

NonAN index usage: 0%

NonAN index locations: []

Counter statistics: Uppercase: 0 , Lowercase: 133071, Digits: 212017, NonAlphaNumeric: 0

All char Frequencies:

character: 5 found: 5012 times

character: 2 found: 22563 times

character: 3 found: 12197 times

character: 8 found: 15008 times

character: 4 found: 13275 times

character: 0 found: 98056 times

character: 1 found: 17861 times

character: f found: 87823 times

character:d found:7221 times

character:7 found:9614 times

character:a found:11148 times

character:6 found:10472 times

character:b found:8189 times

character:9 found:7959 times

character:c found:9172 times

character:e found:9518 times

***********************

generated:5 Packets

***********************

Out[44]:

['5608305852bf2ffd61770e2c827542f20be0b0fcba09db916bd07e1734b04cb0352b1d278068064d19f033bfad6fa90e53d865693fd4fee0214f00000eb0aa2c',

The hash value is '3b083595f276e2f1353a535c32f0f59516fc9328f7673bb80262c4da11c93683afe6dcff8a7a83018d78f41498a0da4d141ebd39c361b1724f2b00000eb0aa2c',

The hash value is '0120961963495c4dab9470738b497eddde07b0d70b357795ad9554d7964761969a6d997205e17eada6fa84eb33dcfb11412f75e04c195001283900000eb0aa2c',

The hash value is '091065d52127bbc6e840e02f8e1316f1c4d9c92a23931c00cdbb8c158368852ef8fabd461b98812b51ec84e1ccc5c04aaa366fbafabec623bd3500000eb0aa2c',

The hash value is '7300cc61151b7af27a578e766f49bebb2de68c48b37a00df1030ae464f456928eedd035303e697208bf58217af728a2a346fda5c8aef0335b82e00000eb0aa2c'



In [46]: x.edap.packets

Out[46]:

['5608305852bf2ffd61770e2c827542f20be0b0fcba09db916bd07e1734b04cb0352b1d278068064d19f033bfad6fa90e53d865693fd4fee0214f00000eb0aa2c',

The hash value is '3b083595f276e2f1353a535c32f0f59516fc9328f7673bb80262c4da11c93683afe6dcff8a7a83018d78f41498a0da4d141ebd39c361b1724f2b00000eb0aa2c',

The hash value is '0120961963495c4dab9470738b497eddde07b0d70b357795ad9554d7964761969a6d997205e17eada6fa84eb33dcfb11412f75e04c195001283900000eb0aa2c',

The hash value is '091065d52127bbc6e840e02f8e1316f1c4d9c92a23931c00cdbb8c158368852ef8fabd461b98812b51ec84e1ccc5c04aaa366fbafabec623bd3500000eb0aa2c',

'7300cc61151b7af27a578e766f49bebb2de68c48b37a00df1030ae464f456928eedd035303e697208bf58217af728a2a346fda5c8aef0335b82e00000eb0aa2c'

Help mode

In [15]: x.help("")
Currently supported methods:
__________________________________________________________________________________________________________________________________________________________________

Method    ||-->Description

----------------------------------------------------------------------------------------------------------------------------

MITMproxy    ||-->This method creates a connection to the RabbitMQ and listens on received messages on the todev queue

____________________________________________________________________________________________________________________________

MITMproxyRQueues    ||-->This method reads from the queue todev and sends the request to the device itself.
____________________________________________________________________________________________________________________________

SmartFuzz    ||-->This method generates packets based on what it has learned from a sniff from either the host or the device.st or the device
____________________________________________________________________________________________________________________________

chgIntrfs            ||-->This method allows you to change and select another interface
____________________________________________________________________________________________________________________________

clearqueues          ||-->this method clears all the queues on the rabbitMQ queues that are set up

____________________________________________________________________________________________________________________________

clonedev             ||-->This method does not need any parameters; it only saves a backup of the device in case you need to share it or use it later.

____________________________________________________________________________________________________________________________

createctrltrsnfDB    ||-->creates a SQLite database containing values that were enumerated from control transfer enumeration

____________________________________________________________________________________________________________________________

createdb             ||-->create the sqlite table and columns from usblyzer captures

____________________________________________________________________________________________________________________________

decodePacketAscii     ||-->This method decodes packet bytes back to Ascii

____________________________________________________________________________________________________________________________

describeFuzz         ||-->This method allows you to describe a packet and select which bytes will be fuzzed

____________________________________________________________________________________________________________________________

devEnumCtrltrnsf    ||-->This method enumerates all possible combinations of a control transfer request

____________________________________________________________________________________________________________________________

devReset||-->This method Resets the device

____________________________________________________________________________________________________________________________

devWrite                ||-->To use this with a method you would write to a device make sure to run the startSniffReadThread(self,endpoint=None, pts=None, queue=None,channel=None)

____________________________________________________________________________________________________________________________

devctrltrnsf           ||-->This method allows you to send ctrl transfer requests to the target device

____________________________________________________________________________________________________________________________

deviceInfo            ||-->gets the complete info only for any usb connected to the host

____________________________________________________________________________________________________________________________

deviceInterfaces        ||-->get all interfaces and endpoints on the device

____________________________________________________________________________________________________________________________

devrandfuzz            ||-->this method allows you to create fixed or random size packets created using urandom

____________________________________________________________________________________________________________________________

devseqfuzz            ||-->This method allows you to create sequential incremented packets and send them to the device

____________________________________________________________________________________________________________________________

findSelect            ||-->This method enumerates all USB devices connected and allows you to select it as a target device as well as its endpoints

____________________________________________________________________________________________________________________________

help               ||-->AutogadgetFS Help method

____________________________________________________________________________________________________________________________

hostwrite          ||-->This method writes packets to the host, either targeting a software or a driver in control of the device

____________________________________________________________________________________________________________________________

hstrandfuzz       ||-->This method allows you to create fixed or random size packets created using urandom and send them to the host queue

____________________________________________________________________________________________________________________________

monInterfaceChng   ||-->Method in charge of monitoring interfaces for changes; this is called from def startMonInterfaceChng(self)

____________________________________________________________________________________________________________________________

newProject        ||-->Creates a new project name if you were testing something else

____________________________________________________________________________________________________________________________

releasedev        ||-->Releases the device and re-attaches the kernel driver

____________________________________________________________________________________________________________________________

removeGadget       ||-->This method removes the gadget from the raspberryPI

____________________________________________________________________________________________________________________________

replaymsgs       ||-->This method searches the USBLyzer parsed database and gives you the option to replay a message or all messages from host to device

_____________________________________________________________________________________________________________

searchmsgs           ||-->This method allows you to search and select all messages for a pattern which were saved from a USBlyzer database creation

____________________________________________________________________________________________________________________________

setupGadgetFS        ||-->setup variables for gadgetFS : Linux Only on Raspberry Pi Zero best option

____________________________________________________________________________________________________________________________

showMessage          ||-->shows messages if error or warn or info

____________________________________________________________________________________________________________________________

sniffdevice          ||-->read the communication between the device to hosts

____________________________________________________________________________________________________________________________

startMITMusbWifi    ||-->Starts a thread to monitor the USB target Device

____________________________________________________________________________________________________________________________

startMonInterfaceChng||-->This method Allows you to monitor a device every 10 seconds in case it suddenly changes its interface configuration.

____________________________________________________________________________________________________________________________

startQueuewrite    ||-->initiates a connection to the queue to communicate with the host

____________________________________________________________________________________________________________________________

startSniffReadThread ||-->This is a thread to continuously read the replies from the device and dependent on what you pass to the method either pts or queue

____________________________________________________________________________________________________________________________

stopMITMusbWifi ||-->Stops the man in the middle thread between the host and the device

____________________________________________________________________________________________________________________________

stopMonInterfaceChang||-->Stops the interface monitor thread

____________________________________________________________________________________________________________________________

stopQueuewrite ||-->Stop the thread in charge of communicationicating with the host machine

____________________________________________________________________________________________________________________________

stopSniffing ||-->Kills the sniffing thread started by startSniffReadThread()

____________________________________________________________________________________________________________________________

usblyzerparse ||-->This method will parse your xml exported from usblyzer and then import them into a database

____________________________________________________________________________________________________________________________



In [16]: x.help("findSelect")

****

[+]Help for findSelect Method:

[-]Signature: findSelect(self, chgint=None)





[+]findSelect Help:

This method lists all connected USB devices and allows you to select it as a target device as well as its endpoints
